| Ref | Part Number | Description |
|---|
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
532071673 |
Cap, Plunger (AYP part number) Price: $3.99 |
| 2 |
532123436 |
Rod, Parking Brake (AYP part number) Price: $4.99 |
| 2 |
94-2703 |
PLUG Price: $1.86 |
| 3 |
112-6967 |
O-RING Price: $2.70 |
| 3 |
532123437 |
Bracket, Parking Brake (AYP part number) Price: $4.46 |
| 4 |
106-5363 |
SHAFT-ADJUSTER Price: $41.05 |
| 4 |
532008883 |
Cover, Pedal (AYP part number) Price: $3.99 |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
532132205 |
Bracket, Clutch/Brake Pedal, L.H. (AYP part number) Price: $4.84 |
| 6 |
322-26 |
SCREW-HH Price: $2.36 |
| 6 |
876020308 |
Pin, Cotter 3/32 x 1/2 (AYP part number) This part replaces 876020312. Price: $1.99 |
| 7 |
819131016 |
Washer 13/32 x 5/8 x 16 Gauge (AYP part number) Price: $3.99 |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
119-4164 |
WASHER-WAVE This part replaces 106-5335. Price: $2.73 |
| 8 |
817490508 |
Screw, Hex Head, Thd., Roll. 5/16-18 x 1/2 (AYP part number) Price: $3.99 |
| 9 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 9 |
876020412 |
Pin, Cotter 1/8 x 3/4 (AYP part number) Price: $3.99 |
| 10 |
137-6132 |
SCREW-ADJUSTER, BEDBAR This part replaces 99-2096. Price: $32.54 |
| 10 |
819131316 |
Washer 13/32 x 13/16 x 16 Gauge (AYP part number) Price: $2.99 |
| 11 |
532123543 |
Rod, Brake, Front (AYP part number) Price: $8.38 |
| 11 |
99-2098 |
WASHER Price: $7.01 |
| 12 |
119-4156 |
SPRING-COMPRESSION This part replaces 99-3755. Price: $0.91 |
| 12 |
532139934 |
Assembly, Clutch/Brake Pedal (AYP part number) Price: $23.69 |
| 13 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 13 |
532123394 |
Rod, Clutch (AYP part number) Price: $7.99 |
| 14 |
532121978 |
Bracket, Lift Shaft (AYP part number) Price: $2.38 |
| 15 |
107-3273-01 |
BEDBAR Price: $303.02 |
| 15 |
532133332 |
Assembly, Brake, Pivot, Arm (AYP part number) Price: $6.71 |
| 16 |
119-4151 |
SCREW-BEDKNIFE This part replaces 57-4910. Price: $0.41 |
| 16 |
819251816 |
Washer 25/32 x 1-1/8 x 16 Gauge (AYP part number) Price: $3.99 |
| 17 |
137-6094 |
BEDKNIFE-EDGEMAX (RM 22IN) This part replaces 108-9095. Price: $166.88 |
| 17 |
812000034 |
Ring, Klip (AYP part number) Price: $2.99 |
| 18 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $2.99 |
| 19 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 20 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 21 |
532144413 |
Rod, Brake, Rear (AYP part number) Price: $12.18 |
| 21 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 22 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 23 |
532126847 |
Bushing, Link Drag Blk (AYP part number) Price: $2.99 |
| 23 |
69-8980 |
WASHER Price: $0.58 |
| 24 |
106-9623 |
BOLT-BEDBAR Price: $18.27 |
| 25 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 26 |
323-12 |
SCREW-HH Price: $1.14 |
| 27 |
108-4269-01 |
WEIGHT Price: $146.07 |
| 27 |
532136780 |
Link, Lift, Rear (AYP part number) Price: $5.99 |
| 28 |
107-2954 |
NUT-ADJUSTER, BEARING Price: $17.63 |
| 28 |
532140777 |
Assembly, Rear Mower Lift (AYP part number) Price: $19.69 |
| 29 |
872110506 |
Bolt, Carriage 5/16-18 UNC x 3/4 (AYP part number) Price: $3.99 |
| 29 |
93-2489 |
BEARING Price: $24.37 |
| 30 |
107-4028 |
SEAL-GREASE Price: $21.51 |
| 30 |
873510500 |
Nut, Hex, Keps 5/16-16 UNC (AYP part number) Price: $5.99 |
| 31 |
532133095 |
Spring, Counterbalance (AYP part number) Price: $6.99 |
| 32 |
137-8432 |
REEL+,7IN FWY(22)8 BLD This part replaces 108-9073. Price: $671.21 |
| 32 |
532133721 |
Link, Lift Lever (AYP part number) Price: $13.90 |
