| Ref | Part Number | Description |
|---|
| 1 |
139-5984 |
CONTROLLER-ELECTRONIC This part replaces 92-5720. Price: $2,183.63 |
| 2 |
33113-070 |
SCREW-HH Price: $2.00 |
| 3 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 4 |
93-2089-03 |
BRACKET-CONTROLLER This part replaces 93-2089. Price: $11.02 |
| 5 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 6 |
66-2750 |
DISCONTINUED Price: Call Us |
| 7 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 8 |
33115-040 |
SCREW-HH Price: $1.22 |
| 9 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 10 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 11 |
70-1480 |
RELAY Price: $105.19 |
| 12 |
33113-016 |
SCREW-HH Price: $0.34 |
| 13 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 16 |
94-1325 |
TIE-MOUNT, PUSH Price: $3.20 |
| 17 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 18 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 19 |
93-2123-03 |
DISCONTINUED This part replaces 93-2123. Price: Call Us |
| 20 |
2412-104 |
CLAMP-R Price: $2.37 |
| 21 |
93-2343 |
DISCONTINUED Price: Call Us |
| 22 |
93-2344 |
DISCONTINUED Price: Call Us |
| 23 |
93-2349 |
WIRE HARNESS Price: $1,348.53 |
| 24 |
3290-415 |
RIVET Price: $0.28 |
| 26 |
92-5753 |
CLAMP-HOSE Price: $2.10 |
| 27 |
93-2036 |
CLAMP - AIR HOSE Price: $8.96 |
| 28 |
68-3270 |
BUMPER-RUBBER Price: $37.99 |
| 29 |
3218-2 |
NUT-JAM Price: $0.25 |
| 30 |
117-9471 |
KIT-SERVICE,GR3250-D STEERING This part replaces 93-2269. Price: $105.67 |
| 31 |
93-2270 |
HYD HOSE ASM Price: $91.88 |
| 34 |
85-4491 |
LIGHT-INDICATOR (INCLUDES LAMP) Price: $173.84 |
| 35 |
93-2035 |
HOSE - AIR CLEANER Price: $81.72 |
| 36 |
93-2255 |
HYD HOSE ASM Price: $52.69 |
| 37 |
93-2256 |
HYD HOSE ASM Price: $52.48 |
| 38 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 39 |
2412-39 |
CLAMP-R Price: $1.70 |
| 40 |
94-4519 |
TUBE-CONVOLUTE Price: $2.24 |
| 41 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 42 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 43 |
93-7276 |
DECAL-DANGER Price: $15.13 |
| 506558302 |
506558302 |
BOLT Price: $3.99 |
| 506599301 |
506599301 |
CONNECTOR Price: $5.99 |
| 506834301 |
506834301 |
SPRING Price: $3.99 |
| 506986402 |
506986301 |
HYDROSTAT 7A646024070 This part replaces 506986402. Price: $1,099.99 |
| 506986501 |
506986501 |
WASHER ** Price: $3.99 |
| 506986601 |
506986601 |
SLEEVE Price: $7.99 |
| 506986701 |
502451901 |
PULLEY B This part replaces 506986701. Price: $37.99 |
| 506986801 |
583350101 |
FAN.BLACK.1A646083070 This part replaces 506986801. Price: $27.99 |
| 506986901 |
502451601 |
TUBE This part replaces 506986901. Price: $17.99 |
| 506987001 |
505131102 |
HOSE CLAMP 20-32 This part replaces 506987001. Price: $4.99 |
| 506987501 |
506987501 |
ROD Price: $32.99 |
| 506988001 |
590324701 |
TANK CAP ASSY This part replaces 506988001. Price: $7.99 |
| 506988201 |
506988201 |
Rod Price: $12.71 |
| 506989001 |
506989001 |
TANK Price: $24.99 |
| 535402809 |
535402809 |
PIN Price: $2.99 |
| 535402816 |
535402816 |
PIN Price: $2.99 |
| 535402817 |
535402817 |
ARM Price: $19.99 |
| 535402829 |
535402829 |
MAGNET Price: $5.17 |
| 535402830 |
535402830 |
HOLDER Price: $4.55 |
| 535402832 |
535402832 |
PLUG Price: $14.99 |
| 535402833 |
535402833 |
PIN Price: $2.99 |
| 535402835 |
535402835 |
LEVER Price: $7.99 |
| 535402837 |
583349301 |
SEAL.19, 19216334280 This part replaces 535402837. Price: $17.99 |
| 535402838 |
535402838 |
ARM Price: $14.99 |
| 535402839 |
535402839 |
RETURN SPRING Price: $11.99 |
| 535402840 |
535402840 |
PIN Price: $3.99 |
| 535402841 |
535402841 |
PIN Price: $2.99 |
| 731231801 |
731231801 |
NUT Price: $3.99 |
| 732211401 |
732211401 |
LOCKNUT M5 Price: $2.99 |
| 735311500 |
735311500 |
RETAINING RING ** Price: $2.99 |
| 735312800 |
735312800 |
Retaining Ring Price: $3.94 |
