| Ref | Part Number | Description |
|---|
| 1 |
98-9567 |
COLLAR Price: $3.78 |
| 2 |
532069180 |
LOCKNUT Price: $2.99 |
| 2 |
98-9369 |
CLIP-CIRCULAR, EXTERNAL Price: $0.70 |
| 3 |
532127533 |
COVER SCREEN Price: $14.99 |
| 3 |
98-9570 |
BEARING-MINIATURIZE Price: $13.60 |
| 4 |
98-9681 |
SPRING-GOVERNOR Price: $12.06 |
| 5 |
532187299 |
UPPER CHUTE 54" Price: $99.99 |
| 5 |
98-9645 |
SPRING-START Price: $11.13 |
| 6 |
107-9083 |
LEVER-THRUST This part replaces 98-9660. Price: $29.76 |
| 6 |
818021008 |
SCREW Price: $4.99 |
| 7 |
532140572 |
INDICATOR DUMP BAG Price: $6.99 |
| 7 |
98-9692 |
ROLLER Price: $11.45 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $4.99 |
| 8 |
98-9568 |
COLLAR Price: $4.68 |
| 9 |
819061216 |
WASHER Price: $3.99 |
| 9 |
98-9571 |
BEARING-MINIATURIZE Price: $8.24 |
| 10 |
532007206 |
SPACER LT Price: $5.99 |
| 10 |
98-9593 |
WASHER-PLAIN Price: $2.33 |
| 11 |
539108086 |
NUT 10-24 ACORN ZD This part replaces 532060867. Price: $3.99 |
| 11 |
98-9659 |
LEVER-FORK Price: $26.50 |
| 12 |
810071000 |
LOCKWASHER #10 Price: $3.99 |
| 12 |
98-9566 |
SHAFT-LEVER, FORK Price: $23.27 |
| 13 |
532109808 |
LATCH.HOOD. Price: $5.99 |
| 13 |
98-9682 |
GASKET Price: $0.95 |
| 14 |
130-8182 |
KIT-SHAFT COVER, FORK LEVER This part replaces 98-9569. Price: $13.53 |
| 14 |
596987401 |
Nuts This part replaces 532125004. Price: $2.99 |
| 15 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532130760. Price: $5.99 |
| 15 |
98-9351 |
BOLT Price: $0.98 |
| 16 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532130759. Price: $5.99 |
| 16 |
99-8380 |
FORK LEVER ASM Price: $172.25 |
| 18 |
532187300 |
CHUTE.BAGGER.LOWER.54" Price: $79.99 |
| 20 |
596039001 |
Screws This part replaces 871161010. Price: $2.99 |
| 26 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 27 |
532176987 |
BAGGER FRAME ASSEMBLY Price: $69.99 |
| 30 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 31 |
532174083 |
PLUG, TUBING END Price: $5.99 |
| 32 |
532176990 |
BAGGER.ASM.FRAME.3BIN.BLACK Price: $84.99 |
| 33 |
532192786 |
BAGGER.HINGE.PIN This part replaces 532128600. Price: $14.99 |
| 34 |
532127534 |
GASKET.COVER.BAGGER Price: $11.99 |
| 35 |
532183286 |
CONTAINER TOP Price: $29.99 |
| 36 |
532129586 |
CONTAINER BOTTOM Price: $59.99 |
| 37 |
532134637 |
BAGGER TOP SEAL Price: $14.52 |
| 38 |
532130895 |
LATCH CER38 Price: $5.99 |
| 39 |
532186601 |
STRIP, REINFORCEMENT Price: $7.18 |
| 40 |
871141008 |
Screw #10-24 x 1/2 Price: $2.99 |
