| Ref | Part Number | Description |
|---|
| 1 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 1 |
703-1812A-0716 |
SEAT PIVOT BRACKET Not Available Price: |
| 2 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
703-3208 |
Track, Seat - w/o Latch Price: $64.46 |
| 3 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 3 |
703-3431 |
SEAT WATCH TRACK Not Available Price: |
| 4 |
703-4149-0716 |
SEAT PIVOT LOWER BRACKET Not Available Price: |
| 4 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 5 |
703-4151-0637 |
SEAT BELT MOUNTING BRACKET Not Available Price: |
| 5 |
75-2970 |
PEDAL-TRACTION Price: $135.64 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
710-1669 |
Screw, Pan Hd. Mach. 5/16-18 x 1.0 Price: $4.56 |
| 6 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
710-3005 |
Screw, Hex Cap, 3/8-16 x 1.25 GR5 Price: $3.61 |
| 7 |
75-6550 |
DISC-FRICTION Price: $7.96 |
| 8 |
710-3038 |
Screw, Hex Cap, 5/16-18 x .875 GR5 Price: $4.17 |
| 8 |
75-6490 |
LEVER ASM Price: $78.45 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
233-42 |
KNOB Price: $12.88 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 10 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 10 |
93-6699 |
DECAL-FAST / SLOW Price: $18.07 |
| 11 |
112-5084 |
BRACKET-LEVER This part replaces 75-6510. Price: $61.39 |
| 11 |
732-0735A |
Compression Spring This part replaces 732-0735. Price: $27.35 |
| 12 |
735-04039 |
SEAT SPRING CAP Not Available Price: |
| 12 |
75-6580 |
CABLE-PEDAL Price: $34.72 |
| 13 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
736-0343 |
Washer, Flat, .33 x 1.25 x .12 Price: $3.90 |
| 14 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
738-0140 |
Screw, Shoulder, .435 x .178:5/16-18 Price: $4.93 |
| 15 |
3290-461 |
WASHER-SPRING Price: $3.89 |
| 15 |
750-0258 |
Spacer, .315 x .75 x .375 Price: $10.00 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 16 |
750-04247 |
SEAT SPACER Not Available Price: |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
957-04023 |
HIGH BACK SEAT Not Available This part replaces 757-04005. Price: |
| 18 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 19 |
322-3 |
SCREW-HH Price: $0.79 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 23 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 24 |
63-7733 |
LH BRAKE CABLE ASM Price: $210.39 |
| 25 |
63-7732 |
RH BRAKE CABLE ASM Price: $210.39 |
| 26 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 28 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
75-1440-03 |
PEDAL-BRAKE, LH Price: $207.74 |
| 30 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 31 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 32 |
75-1430 |
RH BRAKE PEDAL ASM Price: $255.51 |
| 33 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 34 |
75-3270-03 |
HUB-PIVOT, TRACTION Price: $144.73 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
75-1470 |
PIN-PIVOT, BRAKE Price: $45.68 |
| 36 |
75-2170-03 |
TUBE-CONTROL, PUMP Price: $103.73 |
| 37 |
3220-3 |
NUT-HJ Price: $0.28 |
| 38 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 40 |
323-9 |
SCREW-HH Price: $1.29 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
| 777D01782 |
LABEL-MADE |
IN USA Not Available Price: 777D01782 |
| 777D06883 |
Graphic, |
Cub Cadet Price: $15.77 777D06883 |
