| Ref | Part Number | Description |
|---|
| 1 |
82-2850 |
PLATE Price: $21.91 |
| 2 |
82-9680 |
RIVET Price: $0.98 |
| 3 |
82-9700 |
SCREW Price: $1.58 |
| 4 |
82-2730 |
WEAR PARTS KIT Price: $67.73 |
| 5 |
82-2740 |
TENSION SPRING SET Price: $72.36 |
| 6 |
56-4150 |
LEVER This part replaces 56-4140. Price: $71.57 |
| 7 |
82-2870 |
LEVER-ADJUST Price: $43.38 |
| 12 |
82-2800 |
CUSHION-REST, BACK Price: $418.29 |
| 13 |
56-3850 |
SCREW Price: $3.37 |
| 14 |
55-4330 |
LH ARMREST ASM Price: $146.35 |
| 15 |
82-2840 |
CUSHION-BOTTOM Price: $555.71 |
| 16 |
92-2951 |
RAIL-ADJUST, LH Price: $199.04 |
| 17 |
82-9690 |
SCREW Price: $2.67 |
| 18 |
56-4030 |
DISCONTINUED This part replaces 82-9660. Price: Call Us |
| 19 |
82-9650 |
NUT Price: $8.89 |
| 20 |
82-2820 |
SWING ARM ASM Price: $422.94 |
| 21 |
82-2790 |
RAIL-ADJUST, LH Price: $212.20 |
| 22 |
82-9710 |
TRIM-BOTTOM Price: $54.09 |
| 23 |
82-2720 |
FRAME-SEAT Price: $1,045.27 |
| 24 |
82-9640 |
SCREW Price: $0.98 |
| 25 |
82-2810 |
SWITCH ASM Price: $336.01 |
| 26 |
82-9620 |
DISCONTINUED Price: Call Us |
| 27 |
82-9630 |
NUT Price: $1.24 |
| 29 |
56-4170 |
PIN Price: $24.96 |
| 30 |
56-3890 |
NUT Price: $4.04 |
| 31 |
56-3880 |
WASHER Price: $1.33 |
| 32 |
82-9720 |
TRIM-REST, BACK Price: $39.95 |
| 33 |
82-2860 |
SPRING-SET, TENSION Price: $19.71 |
| 34 |
82-2750 |
DISCONTINUED Price: Call Us |
| 35 |
82-2710 |
SCREW Price: $8.39 |
| 37 |
82-2830 |
CLAMP Price: $13.33 |
| 38 |
82-2770 |
SHOCK ABSORBER ASM Price: $221.09 |
| 39 |
82-9670 |
NUT Price: $0.93 |
| 40 |
56-3940 |
WASHER Price: $1.33 |
| 41 |
82-2760 |
BUSHING KIT Price: $9.67 |
| 501003702 |
501003702 |
MAIN WIRING Price: $107.99 |
| 504200801 |
504200801 |
COVER WASHER Price: $3.99 |
| 535087601 |
575231701 |
WHEEL, FRONT This part replaces 535087601. Price: $19.99 |
| 535087801 |
535087801 |
WASHER, SEALING Price: $2.99 |
| 535091201 |
535091201 |
RETAINER, AXLE CAP Price: $2.99 |
| 535120901 |
535120902 |
BATTERY This part replaces 535120901. Price: $149.99 |
| 535122102 |
535122102 |
CUTTING HEIGHT NUT Price: $22.99 |
| 535122401 |
535122401 |
SPRING Price: $3.99 |
| 535123102 |
592852201 |
Circuits This part replaces 535123102. Price: $17.99 |
| 535125201 |
535125201 |
PLUG Price: $4.99 |
| 535125601 |
535125601 |
BRACKET Price: $12.99 |
| 535125701 |
535125701 |
LOUD SPEAKER Price: $19.99 |
| 535130310 |
535130310 |
SCREW Price: $2.99 |
| 535130314 |
535130314 |
SCREW Price: $2.99 |
| 535130316 |
575543316 |
SCREW This part replaces 535130316. Price: $3.99 |
| 535132901 |
535132901 |
WHEEL Price: $102.99 |
| 535135002 |
535135002 |
WHEEL LOGO ADDED Price: $9.99 |
| 535136003 |
535136003 |
GEAR WHEEL Price: $27.99 |
| 535137202 |
535137202 |
WHEEL MOTOR W/GEARBOX Price: $249.99 |
| 535138101 |
535137202 |
WHEEL MOTOR W/GEARBOX This part replaces 535138101. Price: $249.99 |
| 535139201 |
535139201 |
GASKET Price: $14.99 |
| 535139401 |
535139401 |
SCREW Price: $3.99 |
| 535139601 |
535139601 |
HOLDER Price: $4.99 |
| 540056401 |
592852001 |
PRINTED CIRCUIT ASSY PCBA AM22 This part replaces 540056401. Price: $349.99 |
| 544905202 |
544905202 |
HUB CAP Price: $2.99 |
| 544906802 |
544906802 |
HUB Price: $17.99 |
| 544907801 |
544907801 |
BRACKET Price: $8.99 |
| 544918302 |
544918302 |
CHASSIS 220AC Price: $74.99 |
| 734114571 |
734114571 |
Washer 0 5.3 Price: $1.99 |
| 735583509 |
735583509 |
WASHER Price: $2.99 |
