| Ref | Part Number | Description |
|---|
| 1 |
147-0901 |
ARM-PITCH This part replaces 119-9307-01. Price: $179.09 |
| 1 |
532424551 |
WHEEL.STEERING.MLT.BR.YEL/OVRM Price: $64.99 |
| 2 |
117-9456 |
CROSSLINK Price: $54.18 |
| 3 |
119-4012 |
SCREW-HWHTF Price: $0.61 |
| 4 |
120-3221 |
LH REEL NUT ASM Price: $33.34 |
| 5 |
115-3340 |
WEIGHT ASM Price: $136.76 |
| 6 |
115-5227 |
MOTOR ADAPTER ASM Price: $98.96 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 7 |
117-6706 |
CLAMP-MOTOR Price: $34.81 |
| 7 |
532121748 |
WASHER Price: $1.99 |
| 8 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 8 |
812000029 |
RING CLIP Price: $1.99 |
| 9 |
117-6849 |
SHIELD-SPRING Price: $48.38 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
| 10 |
3274-18 |
SCREW-HSH Price: $8.88 |
| 11 |
119-4038 |
NUT-HEX Price: $0.31 |
| 13 |
532121749 |
WASHER Price: $1.99 |
| 14 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $1.99 |
| 16 |
587016002 |
SHAFT.STEER.2HIGH.SPLND.PLATED Price: $11.99 |
| 19 |
532194729 |
PLATE.STEER.DDL.NLT/NG Price: $12.99 |
| 20 |
532424740 |
BOOT.STRNG.PREDATOR.YT/GT.428 Price: $2.99 |
| 21 |
586840201 |
ADAPTER.WHEEL.STEER.SPLND.ALUM Price: $2.99 |
| 22 |
585029901 |
BEARING.SUBASM.SHAFT.STEER.LOW Price: $4.99 |
| 26 |
532424553 |
CAP.WHL.STRNG.MULTI.BRND.YEL Price: $5.99 |
| 27 |
819211616 |
WASHER LT Price: $3.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $19.99 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $1.99 |
| 50 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $2.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $8.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $4.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $3.99 |
| 61 |
532194740 |
DRAGLINK.LH.BALLSTUD.D Price: $44.99 |
| 62 |
532194741 |
DRAGLINK.RH.BALLSTUD.D Price: $44.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $2.99 |
| 67 |
532194737 |
BUSHING.PM.FRONT AXLE Price: $3.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $2.99 |
| 70 |
585338801 |
BRACKET.FRT.DECK.SUSP.RR.MT431 Price: $5.99 |
| 75 |
580683702 |
PINION.ZINC PLATED This part replaces 580683701. Price: $2.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $1.99 |
