| Ref | Part Number | Description |
|---|
| 1 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 1 |
532123634 |
CONTROL ASSY This part replaces 532121192. Price: $6.49 |
| 2 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 3 |
532123634 |
CONTROL ASSY This part replaces 532121193. Price: $6.49 |
| 3 |
60-2160 |
R-CLIP ASM Price: $8.47 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 4 |
532121188 |
BRACKET Price: $4.42 |
| 5 |
33095-00 |
WASHER-FLAT This part replaces 48-9580. Price: $0.25 |
| 6 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 6 |
532121186 |
FAN NLA Price: $16.78 |
| 7 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 7 |
532121180 |
PULLEY TRANSAXLE Price: $50.61 |
| 8 |
532121211 |
STANDOFF Price: $13.99 |
| 8 |
65-5890 |
CAP-END Price: $8.09 |
| 9 |
532121182 |
GUARD ASSY Price: $5.50 |
| 9 |
58-165o |
Rod-Seat Price: Call Us |
| 10 |
82-9340 |
LEVEL SWITCH ASM Price: $201.99 |
| 11 |
65-5870 |
TUBE Price: $20.33 |
| 12 |
71-4040 |
HYD FILLER ASM Price: $69.67 |
| 13 |
353-961 |
FLANGE Price: $29.89 |
| 13 |
506774701 |
CONTAINER This part replaces 532121323. Price: $51.99 |
| 14 |
32144-107 |
SCREW Price: $0.68 |
| 15 |
353-963 |
GASKET Price: $4.33 |
| 15 |
532121250 |
SPRING Price: $3.99 |
| 16 |
62-2610 |
STRAINER-CAP, FILLER Price: $22.31 |
| 17 |
46-0670 |
SCREW-PPH Price: $1.89 |
| 18 |
92-9200 |
COVER Price: $276.63 |
| 19 |
532071673 |
PLUNGER CAP This part replaces 532124236. Price: $4.99 |
| 19 |
60-5580 |
SWITCH-TEMPERATURE Price: $178.50 |
| 20 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 20 |
532007605 |
BOLT This part replaces 532124815. Price: $4.99 |
| 21 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 22 |
58-6820 |
GASKET Price: $13.28 |
| 23 |
58-6530 |
HYD OIL DECAL Price: $12.38 |
| 23 |
93-6686 |
DECAL-OIL, HYD This part replaces 93-8067. Price: $7.01 |
| 24 |
60-0050 |
SPRING-TRAY, SEAT Price: $78.73 |
| 25 |
58-1640 |
PIN-PIVOT, SEAT Price: $59.26 |
| 26 |
66-7650 |
WIRE HARNESS Price: Call Us |
| 27 |
32128-20 |
NUT-HF Price: $0.99 |
| 30 |
58-1580-03 |
FRAME-SEAT This part replaces 58-1580. Price: $402.10 |
| 31 |
58-9830-03 |
PLATE-SEAT This part replaces 58-9830. Price: $355.56 |
| 32 |
5-0652 |
SPACER This part replaces 26-4840. Price: $5.35 |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 34 |
2412-102 |
CLAMP-R Price: $6.85 |
