| Ref | Part Number | Description |
|---|
| 1 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 3 |
112-9599-01 |
SHIELD-FOOT, LH Price: $76.47 |
| 4 |
114-4002 |
DEFLECTOR Price: $122.18 |
| 5 |
112-1478-01 |
SHIELD-FOOT, RH Price: $66.75 |
| 6 |
3230-16 |
SCREW-CARR Price: $1.79 |
| 7 |
114-4004-0P |
ANGLE-REAR This part replaces 114-4004-01. Price: $113.20 |
| 8 |
161-5124-01 |
STRAP-SUPPORT This part replaces 114-4005-01. Price: $40.59 |
| 9 |
112-9591-0P |
CHAMBER ASM-LH This part replaces 112-9591-01. Price: $560.66 |
| 10 |
110-0612-0P |
CHAMBER ASM-CENTER This part replaces 110-0612-01. Price: $266.69 |
| 11 |
112-9593-0P |
CHAMBER ASM-RH This part replaces 112-9593-01. Price: $560.66 |
| 12 |
114-4003 |
DEFLECTOR-LH Price: $20.39 |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
322-3 |
SCREW-HH Price: $0.79 |
| 15 |
121-5347-03 |
BLADE-25.18 INCH, ANGLED This part replaces 108-1958-03. Price: $40.07 |
| 16 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 17 |
92-5816 |
BOLT-BLADE Price: $4.93 |
