| Ref | Part Number | Description |
|---|
| 3 |
503-01554 |
HEX HEAD FLANGE BOLT M10X1.25-80 Price: $3.60 |
| 4 |
503-02006 |
BUSHING 10.3X23X49.4 Price: $11.85 |
| 5 |
503-02821 |
SHOULDER SPACER Price: $3.48 |
| 6 |
503-01375 |
LOCK NUT M10X1.25 Price: $6.13 |
| 7 |
503-02285 |
SHIELD CV BASIC Price: $213.23 |
| 8 |
503-01556 |
BUSHING CAP I Price: $3.77 |
| 9 |
503-00011 |
HEXAGON FLANGE BOLT M6X16 Price: $5.48 |
| 10 |
503P0307B |
BALL JOINT KIT Price: $52.92 |
| 11 |
503-02774 |
UPPER A-ARM ASSEMBLY (FRONT LH) Price: $180.97 |
| 12 |
503-02851 |
LOWER ARM ASSEMBLY (FRONT RH) Price: $210.23 |
| 13 |
503-02775 |
UPPER A-ARM ASSEMBLY (FRONT RH) Price: $180.97 |
| 14 |
503-00096 |
COTTER PIN 2.5X30 Price: $7.48 |
| 15 |
503-01560A |
STABILIZER BAR (FRONT) Price: $161.84 |
| 16 |
503P01561 |
ROD BALL KIT (RIGHT) Price: $58.99 |
| 17 |
503P01562 |
ROD BALL KIT (LEFT) Price: $60.66 |
| 18 |
503-00297 |
BUSHING - RUBBER U-TYPE Price: $13.48 |
| 19 |
503-00298A |
PRESS BLOCK REAR ANTI-ROLL BAR Price: $9.36 |
| 20 |
503-00064 |
SPRING WASHER Price: $5.36 |
| 21 |
503-00409 |
HEX FLANGE BOLT M10X1.25X20 Price: $5.36 |
| 24 |
503-02852 |
LOWER ARM ASSEMBLY (FRONT LH) Price: $224.80 |
| 25 |
503-01564 |
FRONT SHOCK ABSORBER Price: $633.50 |
| 26 |
503-00682 |
HEX FLANGE BOLT M10X1.25X55 Price: $8.63 |
| 27 |
503-00056 |
HEX FLANGE BOLT M10X1.25X60 Price: $8.10 |
| 28 |
503-00305 |
SWING ARM NOZZLE Price: $11.35 |
| 29 |
503-02287 |
SHIELD CV III Price: $226.56 |
| 30 |
503-01395 |
WASHER 10 Price: $3.94 |
