| Ref | Part Number | Description |
|---|
| 1 |
532429667 |
KIT.CONTROL.SPEED.SELECTOR.SNO This part replaces 532198875. Price: $66.99 |
| 1 |
76-1420 |
WHEEL-STEERING Price: $202.69 |
| 2 |
32121-111 |
PIN-ROLL Price: $2.39 |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $3.99 |
| 3 |
532197763 |
DRIVE PLATE WELDMENT Price: $40.99 |
| 3 |
85-6610 |
SHAFT-STEERING Price: $54.65 |
| 4 |
532197764 |
SHAFT.HEX.SHORT Price: $9.99 |
| 5 |
532175344 |
TRUNNION BEARING ASSY Price: $19.99 |
| 5 |
92-5035 |
STEERING POST ASM Price: $105.83 |
| 6 |
812000012 |
RETAINING RING Price: $2.99 |
| 6 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 7 |
65-8770 |
BUSHING-BELLCRANK Price: $5.35 |
| 7 |
872110505 |
BOLT, CARRIAGE 5/16-18 X 5/8 This part replaces 872270505. Price: $3.49 |
| 8 |
532188909 |
BEARING FLANGE Price: $12.99 |
| 8 |
98-0973 |
PIN-GROOVED Price: $2.10 |
| 9 |
532182504 |
SPACER, BEARING Price: $3.99 |
| 9 |
85-9180 |
SPROCKET-STEERING Price: $56.99 |
| 10 |
532184077 |
LEVER.SHIFTER.PLATE.BLACK This part replaces 532435787. Price: $8.99 |
| 11 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 11 |
532435784 |
BRACKET.SHIFTER.SUPPORT.BLACK Price: $2.99 |
| 12 |
3217-7 |
NUT-HEX Price: $0.28 |
| 12 |
532178695 |
PIN, PIVOT LEVER Price: $3.99 |
| 13 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 13 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 14 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 14 |
532403300 |
ROD.CLUTCH.YELLOW.ZINC(VT) Price: $8.99 |
| 15 |
251-166 |
BEARING-FLANGE Price: $14.74 |
| 15 |
817490508 |
Screw, Hex Washer Head Threaded, Rolling 5/16-18 x 1/2 Price: $3.99 |
| 16 |
251-165 |
BEARING-BALL Price: $104.65 |
| 16 |
532184075 |
PLATE.DRIVE.MOUNTING.BLACK This part replaces 532435783. Price: $14.99 |
| 17 |
532155377 |
NUT.FLANGE.5/16 Price: $3.49 |
| 18 |
532191080 |
PULLEY.TRACTION.7.75 Price: $44.99 |
| 19 |
819111507 |
WASHER, FLAT Price: $3.99 |
| 20 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 20 |
810040500 |
LOCKWASHER Price: $2.99 |
| 21 |
18-6380 |
PIN-ADJUSTMENT, STEERING Price: $12.89 |
| 21 |
874950512 |
SCREW Price: $3.99 |
| 22 |
2710-11 |
LINK-CHAIN Price: $5.68 |
| 22 |
532414557 |
SPRING.TRACTION.IDLER Price: $2.99 |
| 23 |
532179095 |
SPRING.RETURN Price: $2.99 |
| 23 |
92-5039 |
CHAIN-STEERING Price: $36.82 |
| 24 |
18-6320 |
WASHER-STEERING Price: $2.65 |
| 24 |
532178828 |
SPRING, BRAKE Price: $2.99 |
| 25 |
115-9472 |
BEARING-CONE AND SEAL This part replaces 254-70. Price: $22.04 |
| 25 |
532410877 |
PAN.BOTTOM.PLASTIC Price: $17.99 |
| 26 |
532184471 |
SCREW, HEX HEAD, TAPPING Price: $2.99 |
| 28 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 29 |
95-0600-01 |
FRAME ASM Price: $2,207.18 |
| 30 |
3272-37 |
PIN-COTTER Price: $0.75 |
| 31 |
32136-9 |
NUT-HEX, SLOTTED Price: $7.44 |
| 32 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 33 |
85-9200 |
KNUCKLE-STEERING Price: $100.34 |
| 34 |
98-0996 |
STEERING SHFT KIT-SANDPRO This part replaces 98-0928. Price: $35.09 |
| 35 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 38 |
94-6821 |
CLAMP-WIRE Price: $3.32 |
| 40 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
