| Ref | Part Number | Description |
|---|
| 1 |
117-0723 |
PLATE-MOUNT, TUBE CLAMP Price: $13.30 |
| 1 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 2 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 2 |
94-8105 |
CLAMP-TUBE Price: $3.17 |
| 3 |
353-987 |
FITTING-ELBOW, 90 Price: $74.72 |
| 4 |
117-0693 |
HYDRAULIC TUBE Price: $61.58 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
340-157 |
FITTING-HYD, TEE Price: $49.83 |
| 5 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 6 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 6 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 7 |
340-70 |
NUT-LOCK Price: $2.10 |
| 8 |
117-0708 |
PUMP CONTROL VALVE ASM Price: $1,425.48 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 10 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 11 |
354-79 |
CAP-DUST Price: $7.81 |
| 12 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
322-14 |
SCREW-HH Price: $1.01 |
| 13 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 14 |
340-129 |
FITTING-ELBOW, 90 DEG Price: $99.81 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 16 |
125-5854 |
TUBE ASM Price: $113.43 |
| 17 |
100-5616 |
FITTING Price: $50.63 |
| 17 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 18 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 19 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 20 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
3230-6 |
BOLT-CARR Price: $0.59 |
| 22 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 23 |
117-0689 |
PLATE-MOUNT, TUBE CLAMPS Price: $17.96 |
| 24 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 25 |
2412-102 |
CLAMP-R Price: $6.85 |
| 25 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 26 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 27 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 28 |
117-0680 |
HOSE ASM Price: $200.68 |
| 29 |
117-0682 |
HOSE ASM Price: $205.74 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
119-0583 |
HOSE ASM Price: $155.32 |
| 31 |
119-5045 |
HOSE-SUCTION Price: $86.98 |
| 31 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA This part replaces 532407489. Price: $99.99 |
| 32 |
117-0687 |
HOSE ASM Price: $181.17 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 33 |
125-5853 |
HYD-HOSE Price: $273.06 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
94-3688 |
SLEEVE-PROTECTIVE Price: $23.04 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 38 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 72 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
