| Ref | Part Number | Description |
|---|
| 1 |
188704 |
Seat Price: Call Us |
| 1 |
98-7520 |
PAN-OIL Price: $443.57 |
| 2 |
108-7053 |
GASKET-PAN, OIL This part replaces 98-7521. Price: $51.05 |
| 2 |
180166 |
Bracket Pivot Fender Price: Call Us |
| 3 |
110-6194 |
BOLT-FLANGE This part replaces 98-7522. Price: $3.22 |
| 3 |
71110616 |
Bolt Fin Hex 3/8-16 unc x 1 Price: Call Us |
| 4 |
19131610 |
Washer 13/32 x 1 x 10 Ga. Price: Call Us |
| 4 |
98-9686 |
PLUG-DRAIN This part replaces 98-7523. Price: $14.50 |
| 5 |
145006 |
Clip Push-In Price: Call Us |
| 5 |
98-7524 |
GASKET Price: $5.09 |
| 6 |
73800600 |
Nut Hex w/Ins. 3/8-16 unc Price: Call Us |
| 6 |
98-7525 |
FILTER-SCREEN Price: $37.40 |
| 7 |
124181X |
Spring Seat Cprsn 2 250 Blk Zi Price: Call Us |
| 7 |
98-7526 |
BOLT Price: $0.80 |
| 8 |
17000616 |
Screw 3/8-16 x 1.5 Smgml Price: Call Us |
| 8 |
98-7527 |
O-RING Price: $1.48 |
| 9 |
19131614 |
Washer 13/32 x 1 x 14 Ga. Price: Call Us |
| 9 |
98-7528 |
O RING-COPPER Price: $1.79 |
| 10 |
180186 |
Pan Seat Price: Call Us |
| 10 |
98-7529 |
PLUG-DRAIN Price: $16.47 |
| 11 |
105-4579 |
GAUGE-OIL Price: $58.87 |
| 11 |
166369 |
Knob Seat Price: Call Us |
| 12 |
121246X |
Bracket Mounting Switch Price: Call Us |
| 13 |
121248X |
Bushing Snap Blk Nyl 50 Id Price: Call Us |
| 14 |
72050412 |
Bolt Rdhd Sqnk 1/4-20 x 1-1/2 Price: Call Us |
| 15 |
134300 |
Spacer Split 28x 88 Price: Call Us |
| 16 |
121250X |
Spring Cprsn Price: Call Us |
| 17 |
123976X |
Nut Lock 1/4 Lge Flg Gr. 5 Zinc Price: Call Us |
| 21 |
171852 |
Bolt Shoulder 5/16-18 unc Price: Call Us |
| 22 |
73800500 |
Nut Hex Lock W/Ins 5/16-18 Price: Call Us |
