| Ref | Part Number | Description |
|---|
| 1 |
98-7765 |
WATER FLANGE ASM Price: $212.88 |
| 2 |
98-7766 |
PIPE-RETURN, WATER Price: $9.95 |
| 3 |
98-7767 |
GASKET-FLANGE, WATER Price: $4.58 |
| 4 |
100-2562 |
BOLT This part replaces 98-7610. Price: $2.79 |
| 5 |
98-7769 |
STUD Price: $1.76 |
| 6 |
99-8336 |
BOLT This part replaces 98-7554. Price: $3.41 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK This part replaces 580962301. Price: $7.99 |
| 7 |
98-7534 |
NUT Price: $0.48 |
| 8 |
98-7535 |
WASHER-SPRING Price: $0.32 |
| 9 |
98-7773 |
PIPE-RETURN, WATER Price: $9.79 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 10 |
98-7774 |
BAND-PIPE Price: $3.88 |
| 13 |
98-7775 |
COVER-THERMOSTAT Price: $15.96 |
| 14 |
105-3748 |
GASKET-THERMOSTAT This part replaces 98-7776. Price: $4.31 |
| 15 |
98-7777 |
BOLT Price: $1.56 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST Price: $9.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464808 |
LINK ASSY LIFT.REAR LINK.ASM.P This part replaces 532197984. Price: $12.99 |
| 98 |
581506904 |
Links This part replaces 532420525. Price: $12.99 |
| 100 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 101 |
581506502 |
LINK.ASSY.BLACK.431 This part replaces 581506501. Price: $11.99 |
| 116 |
594976501 |
Washers This part replaces 819151516. Price: $2.99 |
