| Ref | Part Number | Description |
|---|
| 1 |
58-9580-03 |
REST-FOOT This part replaces 58-9580. Price: $291.45 |
| 2 |
583678201 |
BAIL.CONT.WIRE.DLX.COM.BLK This part replaces 532176580. Price: $14.99 |
| 2 |
76-3280 |
TRACTION PEDAL ASM *R Price: $1,467.21 |
| 3 |
532167163 |
HANDLE, UPPER DLX COMF. (GRIP) Price: $37.99 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 4 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 5 |
532130861 |
CABLE.MZR.51.RT.SP./PU. Price: $10.99 |
| 5 |
60-2110 |
PIN Price: $1.42 |
| 6 |
48-6790 |
BEARING Price: $12.14 |
| 6 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532132004. Price: $1.99 |
| 7 |
532700417 |
THROTTLE CONTROL Price: $17.99 |
| 7 |
68-9400 |
NUT-FLANGE This part replaces 48-7930. Price: $2.29 |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 8 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $4.99 |
| 9 |
3-2858 |
DISC-FRICTION Price: $31.32 |
| 9 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532136376. Price: $9.99 |
| 10 |
60-1130 |
LEVER Price: $177.91 |
| 11 |
3290-483 |
WASHER-CONICAL Price: $7.61 |
| 12 |
325-9 |
SCREW-HH Price: $1.87 |
| 13 |
47-7030 |
BUSHING-RUBBER Price: $31.76 |
| 14 |
33024-00 |
NUT-LOCK, NI This part replaces 48-9510. Price: $0.75 |
| 15 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532164265. Price: $4.99 |
| 15 |
68-9400 |
NUT-FLANGE This part replaces 48-7930. Price: $2.29 |
| 16 |
3217-9 |
NUT-HH Price: $0.37 |
| 16 |
532150050 |
SCREW.HXTAP.10-24 Price: $2.99 |
| 17 |
3290-482 |
WASHER-BELLEVILLE Price: $5.87 |
| 17 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 18 |
33114-035 |
SCREW-HH This part replaces 48-7740. Price: $3.77 |
| 18 |
532150050 |
SCREW.HXTAP.10-24 Price: $2.99 |
| 19 |
48-7100 |
DAMPER-STEERING Price: $441.57 |
| 19 |
532700325 |
WHEEL ADJUSTING BRACKET This part replaces 532155047. Price: $3.99 |
| 20 |
3219-5 |
NUT-HEX Price: $1.22 |
| 20 |
532084596 |
ENGINE.PULLEY.FWG Price: $27.99 |
| 21 |
532087677 |
HI PRO KEY PM WSL Price: $3.99 |
| 21 |
58-4310 |
COLLAR-PINNED Price: $51.49 |
| 22 |
58-5100 |
WASHER-TRACTION Price: $28.50 |
| 23 |
532133040 |
REAR BAFFLE This part replaces 532125348. Price: $4.99 |
| 23 |
60-5700 |
SPRING Price: $27.02 |
| 24 |
532413160 |
SKIRT.REAR.22RD/SD.FO/VE This part replaces 532140540. Price: $11.99 |
| 24 |
58-9010 |
TAB-CLAMP Price: $60.87 |
| 25 |
532138860 |
SIDE BAFFLE Price: $3.16 |
| 25 |
60-6540 |
BOLT Price: $3.27 |
| 26 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 26 |
532166800 |
BACK PLATE Price: $6.39 |
| 27 |
3250-40 |
SCREW-SPH Price: $0.54 |
| 27 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 28 |
532054583 |
SCREW Price: $4.99 |
| 28 |
58-7800 |
D LEVER W.A. *B Price: $328.78 |
| 29 |
532176041 |
BAFFLE, DISCHARGE This part replaces 532180857. Price: $9.57 |
| 29 |
60-6990 |
WASHER Price: $4.62 |
| 30 |
3255-24 |
WASHER-LOCK / EXT Price: $0.25 |
| 30 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532179585. Price: $7.99 |
| 31 |
3217-29 |
NUT-HEX Price: $0.25 |
| 31 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 32 |
3274-7 |
SCREW-HSH Price: $0.91 |
| 32 |
532175245 |
HANDLE.LOWER.21.FWGD.BLACK This part replaces 532153605. Price: $19.99 |
| 33 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 33 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 34 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 34 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 35 |
112-6500-01 |
BRACKET-LOCK, NEUTRAL This part replaces 60-0730. Price: $300.58 |
| 36 |
58-0800 |
DISCONTINUED Price: Call Us |
| 37 |
3296-19 |
NUT-HEX Price: $0.65 |
| 38 |
532752063 |
WHEEL.14X2.PR.SP.RAD.GY Price: $69.99 |
| 38 |
60-6740 |
WASHER Price: $2.31 |
| 39 |
48-6940 |
SPRING Price: $30.61 |
| 39 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532142748. Price: $7.99 |
| 40 |
532401630 |
WASHER.CURVED.CYLINDRICAL This part replaces 532061651. Price: $3.99 |
| 40 |
58-7290 |
DISCONTINUED Price: Call Us |
| 41 |
532750913 |
ARM.ASM.AXLE.REAR.BZP. This part replaces 532162233. Price: $5.99 |
| 42 |
532198456 |
SPRING.SELECTOR.EXTENSION This part replaces 532177132. Price: $5.99 |
| 42 |
60-0760 |
CLEVIS-ROD, TRACTION Price: $42.76 |
| 43 |
33094-00 |
WASHER-PLAIN This part replaces 48-8030. Price: $0.25 |
| 43 |
532175477 |
SELECTOR KNOB Price: $3.99 |
| 44 |
33114-020 |
SCREW-HH This part replaces 66-3160. Price: $0.28 |
| 44 |
532128415 |
RIVET BLIND Price: $3.99 |
| 45 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532146630. Price: $3.99 |
| 45 |
58-0400-01 |
SHROUD This part replaces 58-0400. Price: $472.86 |
| 46 |
62-7400 |
DECAL Price: $24.54 |
| 47 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 47 |
60-0600-03 |
BRACKET-PIVOT This part replaces 60-0600. Price: $236.10 |
| 48 |
60-1110 |
BUSHING Price: $15.95 |
| 49 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 50 |
325-8 |
SCREW-HH Price: $3.52 |
| 50 |
532195914 |
BRKT.ASM.HND/HW.RT.BLACK This part replaces 532177130. Price: $11.99 |
| 51 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 51 |
532195915 |
BRACKET.ASM.HDL.LT.EZEM.22.BLA This part replaces 532177131. Price: $11.99 |
| 52 |
2411-44 |
END-ROD Price: $72.59 |
| 52 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 53 |
76-3350 |
SPACER Price: $19.77 |
| 54 |
532125078 |
WASHER.ENGINE.BZP Price: $4.99 |
| 54 |
76-3430 |
ROD-TRACTION Price: $79.20 |
| 55 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 55 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 56 |
3211-6 |
SCREW-HH Price: $3.87 |
| 57 |
3256-45 |
WASHER-FLAT Price: $0.28 |
| 57 |
532170557 |
KIT.BAFFLE.FRT.22RD.FO.PU/FWGD Price: $27.99 |
| 58 |
76-3370 |
BUSHING Price: $7.93 |
| 59 |
3256-76 |
WASHER-FLAT Price: $1.42 |
| 59 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 60 |
32121-11 |
PIN-ROLL Price: $0.47 |
| 60 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 61 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 61 |
76-3340 |
LINK *R Price: $61.84 |
| 62 |
532141114 |
BLADE 22" Price: $24.99 |
| 62 |
76-3330 |
DISCONTINUED Price: Call Us |
| 63 |
532851514 |
BLADE ADAPTOR Price: $7.99 |
| 64 |
532176583 |
MWR HOUSING KIT Price: $127.81 |
| 68 |
532088652 |
HINGE SCREW Price: $3.99 |
| 69 |
532166649 |
PLUG.MULCH.22RD Price: $27.99 |
| 70 |
532048283 |
KIT.SHIELD.DEBRIS.21.RWGD.EZ This part replaces 532134612. Price: $12.99 |
| 75 |
874760612 |
BOLT Price: $3.99 |
| 77 |
532088348 |
WASHER.FLAT.1/2 Price: $3.99 |
| 78 |
532147738 |
DOOR.ASM.MULCHER.COMBI-CUT. This part replaces 532150757. Price: $24.99 |
| 79 |
532428450 |
KIT.O-RING/WASHER This part replaces 532057143. Price: $3.99 |
| 82 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
| 83 |
532125078 |
WASHER.ENGINE.BZP This part replaces 532213146. Price: $4.99 |
| 84 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 85 |
532145285 |
CLIP-ON DISCHARGE DEFLECTOR This part replaces 532150653. Price: $8.99 |
| 86 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 89 |
532184193 |
BOLT This part replaces 532165912. Price: $4.99 |
| 91 |
532170939 |
DOOR SPRING RH Price: $5.99 |
| 92 |
532170938 |
DOOR SPRING LH Price: $4.99 |
| 530402152 |
WARNING |
DECAL This part replaces 532162300. Price: $1.33 530402152 |
