| Ref | Part Number | Description |
|---|
| 1 |
120-9074 |
TUBE-FAN Price: $139.90 |
| 1 |
532400108 |
NEEDS DESCRIPTION Price: Call Us |
| 2 |
120-8966 |
TUBE-DRAIN, FAN Price: $107.67 |
| 2 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 3 |
120-9075 |
TUBE-FAN Price: $135.99 |
| 3 |
532165569 |
BRACKET Price: $23.99 |
| 4 |
532165558 |
BRACKET Price: $14.76 |
| 4 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 5 |
132-6145 |
TUBE-HYD Price: $47.65 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
117-3123 |
HYD HOSE ASM Price: $72.11 |
| 6 |
532165557 |
BAR.SWAY.92.CRD Price: $6.99 |
| 7 |
120-9078 |
TUBE-HYD Price: $204.25 |
| 8 |
121-1509 |
TUBE-HYD Price: $170.16 |
| 8 |
583116901 |
BOLT.3/8-24X1.25 GR8 This part replaces 532181712. Price: $5.99 |
| 9 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
132-6146 |
TUBE-HYD Price: $51.07 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 11 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 11 |
532186385 |
NEEDS DESCRIPTION Price: Call Us |
| 12 |
340-70 |
NUT-LOCK Price: $2.10 |
| 13 |
121-1567 |
HOSE-HYD Price: $113.40 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 14 |
121-1565 |
TUBE-TEE Price: $94.35 |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 15 |
121-1510 |
TUBE-HYD Price: $113.53 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
121-1566 |
HOSE-HYD Price: $121.89 |
| 16 |
532186386 |
NEEDS DESCRIPTION Price: Call Us |
| 17 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 17 |
86-2440 |
HOSE-HYD Price: $71.83 |
| 18 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 19 |
121-1544 |
COVER-HOSE Price: $3.91 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
121-1504 |
HOSE-HYD Price: $258.48 |
| 20 |
583117001 |
BOLT.3/8-24X1.25GR8. LHTHRD This part replaces 532181713. Price: $3.99 |
| 21 |
127-9632 |
HOSE-HYD Price: $116.52 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
121-1503 |
HOSE-HYD Price: $248.88 |
| 22 |
532199590 |
NEEDS DESCRIPTION Price: Call Us |
| 23 |
354-79 |
CAP-DUST Price: $7.81 |
| 23 |
532165446 |
BRACKET Price: $5.99 |
| 24 |
532165242 |
BRACKET Price: $12.99 |
| 25 |
532165244 |
BRACKET Price: $22.99 |
| 26 |
583259301 |
BRACE.SUSP.FRONT.CRD/36.2006 This part replaces 532400110. Price: $29.99 |
| 27 |
532165568 |
BRACKET Price: $22.99 |
| 28 |
532165567 |
BRACKET Price: $17.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173435 |
MANDREL.PULLEY.38.BRIGHT.ZINC This part replaces 532153532. Price: $19.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
532400107 |
NEEDS DESCRIPTION Price: Call Us |
| 35 |
532400106 |
NEEDS DESCRIPTION Price: Call Us |
| 36 |
593787801 |
PULLEYS This part replaces 532146763. Price: $27.99 |
| 40 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 41 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 44 |
532175538 |
NEEDS DESCRIPTION Price: Call Us |
| 45 |
532175539 |
COVER.MANDREL.RH.CRD Price: $17.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 55 |
583252901 |
ARM.IDLER.92.CRD./2006 This part replaces 532199498. Price: $22.99 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 61 |
583252601 |
SPRING.TENSION.92.CRD.2006 This part replaces 532199486. Price: $8.99 |
| 68 |
532402008 |
BELT.DRIVE.92CM.CRD.2006 Price: $69.99 |
| 69 |
532165482 |
SHAFT.ASM.W/LWR.BRG.RH.THREAD Price: $59.99 |
| 84 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 118 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 124 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 130 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 131 |
532165661 |
CHUTE BAGGER Price: $79.99 |
| 254 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 295 |
532412171 |
NEEDS DESCRIPTION Price: Call Us |
| 296 |
872110407 |
BOLT.CARRIAGE.1/4-20 X 7/8 This part replaces 872140406. Price: $3.99 |
| 297 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873930400. Price: $3.99 |
