| Ref | Part Number | Description |
|---|
| 1 |
140064 |
SPRING CLUTCH MWR Price: Call Us |
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 2 |
165723 |
SPACER.RETAINER.MOWER Price: Call Us |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 3 |
73680600 |
SUB= 73690600 Price: Call Us |
| 4 |
130840 |
BRAKE ASM Price: Call Us |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
131251 |
IDLER BELT GUIDE Price: Call Us |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 6 |
121316X |
PULLEY IDLER Price: Call Us |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 7 |
72110616 |
BOLT Price: Call Us |
| 8 |
19131410 |
WASHER Price: Call Us |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 9 |
127744 |
SUB= 140092 Price: Call Us |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 10 |
72140610 |
BOLT.3/8-14X1.25 Price: Call Us |
| 11 |
130841 |
BRAKE ROD Price: Call Us |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 13 |
72140506 |
BOLT Price: Call Us |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
73680500 |
SUB= 73690500 Price: Call Us |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
128508 |
MOWER LINK STAB Price: Call Us |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 22 |
10030600 |
SUB= 10040600 Price: Call Us |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
850857 |
BLADE BOLT Price: Call Us |
| 24 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 28 |
153531 |
PULLEY.MAND.36/46 Price: Call Us |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
137266 |
SUB= 139729 Price: Call Us |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
136631 |
SUB= 532136631 Price: Call Us |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
17490508 |
SCREW LT Price: Call Us |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 33 |
131560X428 |
SHIELD, DEFLECTOR Price: Call Us |
| 36 |
121980X |
HINGE ROD Price: Call Us |
| 37 |
123713X |
SPRING TORSION Price: Call Us |
| 38 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 39 |
19111016 |
WASHER Price: Call Us |
| 40 |
110452X |
NUT PUSH M Price: Call Us |
| 41 |
131264 |
V-BELT.PRIM.78.5. Price: Call Us |
| 42 |
19171616 |
WASHER Price: Call Us |
| 43 |
163552 |
RETAINER SPRING Price: Call Us |
| 44 |
140608 |
KEEPER BELT LH Price: Call Us |
| 45 |
110485X |
BEARING Price: Call Us |
| 46 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 47 |
129895 |
BEARING.BALL Price: Call Us |
| 48 |
137645 |
SUB= 137646 Price: Call Us |
| 49 |
133943 |
HARDENED WASHER Price: Call Us |
| 62 |
153390 |
WASHER.FELT. Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
