| Ref | Part Number | Description |
|---|
| 1 |
873640400 |
Nut, Hex Keps 1/4-20 Price: $2.99 |
| 2 |
532108423 |
Assembly, Cable Price: $5.99 |
| 3 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144924. Price: $138.99 |
| 5 |
532108236 |
Bracket, Switch Price: $2.99 |
| 6 |
539101080 |
SWITCH.N.C *SUBS/1* This part replaces 532109553. Price: $4.99 |
| 8 |
817021008 |
Screw, Hex Hd. Tap #10-24 x 1/2 Price: $1.99 |
| 9 |
532140401 |
Key, Molded Price: $3.69 |
| 10 |
107-7824 |
CRANKCASE ASM Price: $13,401.89 |
| 10 |
532141226 |
Cover, Key Ignition Price: $3.99 |
| 11 |
532145774 |
KIT-WASHER/NUT This part replaces 532140400. Price: $3.99 |
| 12 |
532158913 |
IGNITION SWITCH KIT This part replaces 532144921. Price: $37.99 |
| 15 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $7.99 |
| 17 |
532108824 |
Fuse Price: $3.99 |
| 18 |
532128353 |
Assembly, Cable Price: $3.99 |
| 19 |
532146064 |
Harness, Ignition Price: $100.99 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $3.99 |
| 20 |
98-9398 |
CAP-SEALING Price: $6.08 |
| 21 |
810040400 |
WASHER, LOCK 1/4 This part replaces 810090400. Price: $3.99 |
| 22 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 871110408. Price: $1.99 |
| 24 |
532154336 |
Cover, Terminal Red This part replaces 532131563. Price: $4.99 |
| 25 |
532146154 |
KIT SOLENOID .95 This part replaces 532145673. Price: $14.99 |
| 26 |
874760412 |
Bolt, Hex Hd. 1/4-20 UNC x 3/4 Price: $3.99 |
| 27 |
819091016 |
Washer 9/32 x 5/8 x 16 Price: $2.99 |
| 28 |
810040400 |
Washer, Lock 1/4 Price: $3.99 |
| 30 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 30 |
98-7539 |
CAP-SEALING Price: $6.44 |
| 31 |
532004152 |
Bulb, Light Price: $2.99 |
| 32 |
532136850 |
Harness, Headlight Price: $15.99 |
| 33 |
532110712 |
Switch, Light Price: $4.99 |
| 35 |
810040500 |
Washer Lock Hvy Hlcl Spr 5/16 This part replaces 811050500. Price: $2.99 |
| 36 |
811150400 |
Washer Lock Inter. Tooth 1/4 Price: $2.99 |
| 39 |
532141735 |
Bracket Switch Clutch Price: $2.99 |
| 40 |
98-9687 |
PLUG This part replaces 98-7540. Price: $2.86 |
| 50 |
99-8347 |
JOINT-PIPE, DRAIN Price: $52.64 |
| 55 |
817490508 |
Screw, Hex Washer Head Threaded, Rolling 5/16-18 x 1/2 Price: $3.99 |
| 60 |
98-9597 |
PLUG Price: $17.66 |
| 70 |
98-7487 |
PLUG Price: $3.18 |
| 80 |
98-9379 |
PLUG-EXPANSION This part replaces 98-7489. Price: $0.76 |
| 90 |
98-9668 |
PLUG-EXPANSION Price: $2.17 |
| 100 |
98-9375 |
PIN-STRAIGHT Price: $0.41 |
| 110 |
98-9377 |
PIN-STRAIGHT Price: $1.00 |
| 120 |
105-3795 |
PIN-STRAIGHT Price: $0.99 |
| 130 |
98-9387 |
PIN-PIPE Price: $2.92 |
| 140 |
98-9539 |
PIN-PIPE Price: $1.15 |
| 150 |
98-9599 |
PLUG Price: $6.08 |
| 160 |
98-9630 |
PIN-SPRING, START Price: $1.47 |
| 170 |
98-9675 |
PLUG Price: $8.54 |
| 180 |
98-9656 |
BUSHING-GOVERNOR, GEAR Price: $29.04 |
| 190 |
98-7507 |
PLUG Price: $2.64 |
| 200 |
98-7428 |
GASKET Price: $0.68 |
| 210 |
98-9416 |
SWITCH-OIL Price: $47.25 |
| 220 |
99-3447 |
PLUG Price: $3.11 |
