| Ref | Part Number | Description |
|---|
| 1 |
532170551 |
CONTROL.THROTTLE/CHOKE.BLACK This part replaces 532140310. Price: $24.99 |
| 1 |
X-25-20 |
Washer-Plain Price: Call Us |
| 2 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 2 |
X-154-3 |
Screw-H.C. Price: Call Us |
| 3 |
277078 |
Gasket-Governor Housing Price: Call Us |
| 4 |
532137348 |
MUFFLER.SINGLE.B&S.10-12HP Price: $89.99 |
| 4 |
X-343 |
Connector Price: Call Us |
| 5 |
48-353-05 |
Line, Oil Price: Call Us |
| 6 |
271151 |
Rod-Throttle Price: Call Us |
| 7 |
X-70-3 |
Nut Price: Call Us |
| 8 |
45-208-03 |
Joint, Ball Price: Call Us |
| 9 |
X-5-26 |
Screw Price: Call Us |
| 10 |
X-19-1 |
Washer-Lock Price: Call Us |
| 11 |
X-20-1 |
Washer Price: Call Us |
| 12 |
X-70-2 |
Nut-Hex Price: Call Us |
| 13 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED Price: $8.99 |
| 13 |
X-70-3 |
Nut Price: Call Us |
| 14 |
813280324 |
Nipple Pipe 3/8 Npt X 3-1/2 Price: $3.12 |
| 14 |
X-974 |
Screw, H.H.M. Price: Call Us |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 15 |
X-131-1 |
Screw, Price: Call Us |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 16 |
X489-8 |
Rod, Breaker Push Price: Call Us |
| 17 |
52-041-11 |
Gasket Cover Price: Call Us |
| 18 |
220074 |
Diaphram Price: Call Us |
| 19 |
232535 |
Cover Price: Call Us |
| 20 |
271547 |
Spring Governor Price: Call Us |
| 21 |
275691 |
Screw Shoulder Price: Call Us |
| 22 |
277073 |
Gasket Price: Call Us |
| 23 |
277080 |
Lever-Throttle Price: Call Us |
| 23 |
532159880 |
PROTECTOR Price: $7.99 |
| 24 |
277341 |
Washer Price: Call Us |
| 25 |
48-150-03 |
Breaker Price: Call Us |
| 26 |
48-194-01 |
Ball Price: Call Us |
| 27 |
A-277905 |
Housing, Breather (Includes Valve) Price: Call Us |
| 28 |
48-310-28 |
Kit, Governor Price: Call Us |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
X-75-3 |
Plug Price: Call Us |
| 30 |
X-18-1 |
Washer-Lock Price: Call Us |
| 31 |
532180645 |
GAS TANK 2GAL This part replaces 532161911. Price: $59.99 |
| 31 |
X42-2 |
Key, Woodruff Price: Call Us |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 32 |
X49-1 |
Screw, R.H.M. Price: Call Us |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 33 |
X-174-2 |
Screw-F.H. Price: Call Us |
| 34 |
X-269-15 |
Ring-Retainer Price: Call Us |
| 35 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 35 |
X-293-3 |
Bearing-Needle Price: Call Us |
| 36 |
X-293-2 |
Bearing-Needle Price: Call Us |
| 37 |
48-030-02 |
Bearing, Needle Price: Call Us |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 38 |
237022 |
Washer Price: Call Us |
| 39 |
X-324-7 |
Elbow Price: Call Us |
| 40 |
240202 |
Bearing-Ball Price: Call Us |
| 40 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 41 |
275055 |
Seal-Oil Price: Call Us |
| 42 |
277099 |
Gasket, Gov. Cover Price: Call Us |
| 43 |
277100 |
Bearing-Roller Thrust Price: Call Us |
| 44 |
277101 |
Race-Thrust Bearing Price: Call Us |
| 44 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 45 |
277102 |
Race-Thrust Bearing Price: Call Us |
| 46 |
277104 |
Ring-Retaining Price: Call Us |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 47 |
277561 |
Gear-Governor Price: Call Us |
| 48 |
48-081-02 |
Housing Price: Call Us |
| 49 |
48-096-05 |
Cover, Governor Price: Call Us |
| 50 |
48-755-01 |
Kit, Sleeve Price: Call Us |
| 51 |
48-471-02 |
Yoke, Governor Price: Call Us |
| 52 |
48-087-03 |
Lever, Governor Price: Call Us |
| 53 |
48-420-08 |
Shaft, Governor Assy. Price: Call Us |
| 54 |
X42-8 |
Key, Woodruff Price: Call Us |
| 55 |
X-269-4 |
Ring Retaining Price: Call Us |
| 56 |
X-280-8 |
Pin-Roll Price: Call Us |
| 57 |
230080 |
Pin-Flyweight Price: Call Us |
| 58 |
230134 |
Pin, Gov. Wt. Price: Call Us |
| 59 |
48-089-01 |
Spring Price: Call Us |
| 60 |
277114 |
Flyweight Price: Call Us |
| 61 |
277117 |
Weight-Governor Price: Call Us |
| 62 |
277007 |
Shaft-Governor Price: Call Us |
| 62 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 78 |
874760620 |
BOLT This part replaces 817490620. Price: $4.99 |
| 81 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 532128861. Price: $2.99 |
