| Ref | Part Number | Description |
|---|
| 1 |
33-4220 |
DISCONTINUED Price: Call Us |
| 1 |
530047721 |
Bulb-Purge Price: $3.99 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
530071717 |
Kit-Choke Lever Price: $7.99 |
| 3 |
30-3970 |
DISCONTINUED Price: Call Us |
| 3 |
530015843 |
Screw-tank Price: $1.99 |
| 4 |
30-1460 |
DISCONTINUED Price: Call Us |
| 4 |
530057973 |
Assy - Fuel Cap w/retainer This part replaces 530049386. Price: $7.99 |
| 5 |
26-0070 |
DISCONTINUED Price: Call Us |
| 5 |
530095646 |
Assy-Fuel pickup Price: $2.99 |
| 6 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 6 |
530069247 |
Kit-Fuel Line This part replaces 530071404. Price: $3.99 |
| 7 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 7 |
530069216 |
Kit-Fuel/Purge line Price: $3.99 |
| 8 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 8 |
530015775 |
Screw Price: $1.99 |
| 9 |
302-11 |
FITTING-LUBE, 45 DEG This part replaces 302-4. Price: $1.56 |
| 9 |
530054935 |
Cover-Air box Price: $1.99 |
| 10 |
33-4160 |
DISCONTINUED Price: Call Us |
| 10 |
530054946 |
Filter-Air Price: $1.99 |
| 11 |
33-4090 |
DISCONTINUED Price: Call Us |
| 11 |
530015849 |
Screw-Carb. Price: $1.99 |
| 12 |
33-4040 |
DISCONTINUED Price: Call Us |
| 12 |
530054934 |
Box-Air Price: $3.99 |
| 13 |
256-27 |
BUSHING Price: $8.21 |
| 14 |
33-4140 |
DISCONTINUED Price: Call Us |
| 14 |
530071401 |
Gasket-Carb.(kit) Price: $3.99 |
| 15 |
32128-20 |
NUT-HF Price: $0.99 |
| 15 |
545075305 |
Assy-Fuel Tank Price: $11.99 |
| 16 |
30-9020 |
DISCONTINUED Price: Call Us |
| 16 |
530015771 |
Screw-Crankcase Price: $1.99 |
| 17 |
3290-495 |
PIN-KLIK This part replaces 32-0140. Price: $5.47 |
| 17 |
530015952 |
Screw-Shroud Price: $1.99 |
| 18 |
33-0330 |
DISCONTINUED Price: Call Us |
| 18 |
530058797 |
Shroud Price: $14.99 |
| 19 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 19 |
530071401 |
O-ring-Shroud (kit) Price: $3.99 |
| 20 |
30-9880 |
DISCONTINUED Price: Call Us |
| 20 |
530027593 |
Valve-Reed Price: $1.99 |
| 21 |
32-7810 |
DISCONTINUED Price: Call Us |
| 21 |
530054596 |
Stop-Reed Price: $1.99 |
| 22 |
325-18 |
SCREW-HH Price: $3.19 |
| 22 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 23 |
30-1670 |
DISCONTINUED Price: Call Us |
| 23 |
530015875 |
Screw-Retainer Price: $1.99 |
| 24 |
30-0020 |
DISCONTINUED Price: Call Us |
| 24 |
530055492 |
Isolator-Tank Price: $1.99 |
| 25 |
32128-23 |
NUT-HF Price: $1.51 |
| 25 |
530054941 |
Ret.-Tank Price: $1.99 |
| 26 |
30-4770 |
DISCONTINUED Price: Call Us |
| 26 |
530054834 |
Handle-Starter Price: $1.99 |
| 27 |
33-3090 |
BUSHING Price: $7.70 |
| 27 |
530071325 |
Kit-Rope Price: $3.99 |
| 28 |
302-5 |
FITTING-GREASE This part replaces 21-6010. Price: $0.59 |
| 28 |
530032103 |
Bearing-Inner Price: Call Us |
| 29 |
32-1910 |
DISCONTINUED Price: $1.44 |
| 29 |
530015787 |
Retainer Price: $1.99 |
| 30 |
36-2780 |
DISCONTINUED Price: Call Us |
| 30 |
530019158 |
Seal Price: $2.99 |
| 31 |
3217-7 |
NUT-HEX Price: $0.28 |
| 31 |
530032102 |
Bearing-Outer Price: $8.99 |
| 32 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 32 |
530015789 |
Ret.-Crankshaft Price: $2.99 |
| 33 |
530028807 |
Assy-Crankshaft Price: $19.99 |
| 33 |
95-1823 |
WASHER This part replaces 3-3391. Price: $29.18 |
| 36 |
530055524 |
Assy-Flywheel Price: $22.99 |
| 37 |
530016030 |
Washer Price: $1.99 |
| 38 |
530055620 |
Spacer Price: $4.99 |
| 39 |
530015775 |
Screw-Baffle Price: $1.99 |
| 40 |
545115201 |
Plate-Baffle This part replaces 530054939. Price: $2.99 |
| 41 |
530016391 |
Screw-Rope Price: $1.99 |
| 43 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 44 |
530019182 |
Grommet Price: $1.99 |
| 45 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 46 |
530059254 |
Assy.-Fan Housing Price: $17.99 |
| 47 |
530094189 |
Washer-Clutch Price: $2.99 |
| 48 |
530055122 |
Assy-Clutch Price: $8.99 |
| 49 |
530028799 |
Drum-Clutch Price: $4.48 |
| 50 |
530010960 |
Assy-Conn. Rod Price: $14.99 |
| 51 |
530015162 |
Ret.-Piston pin Price: $1.99 |
| 52 |
530012594 |
Ring-Piston Price: $3.99 |
| 54 |
530071401 |
Gasket-Cylinder(kit) Price: $3.99 |
| 55 |
530058846 |
Assy-Leadwire Price: $4.99 |
| 56 |
530069310 |
Kit-Muffler Price: $9.99 |
| 57 |
530058957 |
Shield Price: $3.99 |
| 58 |
530036409 |
Spring-Muffler Price: $1.99 |
| 59 |
530071582 |
Kit-Cylinder This part replaces 530012488. Price: $19.99 |
| 60 |
952030249 |
Plug-Spark(RCJ-6Y) Price: $3.99 |
| 61 |
530001624 |
Bolt-Cyl. 1/4-20" Price: $1.99 |
| 62 |
545081826 |
Kit - Ignition Module This part replaces 530039234. Price: $32.99 |
| 63 |
530016357 |
Screw-Module Price: $1.99 |
