| Ref | Part Number | Description |
|---|
| 1 |
104-0000-03 |
PULLEY Price: $400.11 |
| 1 |
872170410 |
Bolt, Carriage 1/4-20 x 1 1/4 Price: $2.99 |
| 2 |
532127422 |
Seat Price: $181.05 |
| 2 |
99-6937 |
FAN Price: $304.08 |
| 3 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 3 |
874641008 |
Screw, Slotted Pan Head 10-32 x 1/2 Price: $2.99 |
| 4 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 5 |
532139888 |
Bolt Shoulder 5/16-18 Type T.T.T.R. This part replaces 532105529. Price: $2.99 |
| 6 |
532124967 |
Clip, Insulated Price: $5.46 |
| 7 |
251-318 |
BEARING-BALL Price: $16.40 |
| 7 |
873161000 |
This part replaces 873951000. Price: $1.99 |
| 8 |
104-0001 |
SPACER Price: $25.45 |
| 8 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 This part replaces 874760612. Price: $3.99 |
| 9 |
104-0017 |
HUB This part replaces 104-0017-03. Price: $185.06 |
| 9 |
532126471 |
Clip, Insulated Price: $2.99 |
| 10 |
323-12 |
SCREW-HH Price: $1.14 |
| 10 |
532126656 |
Bracket, Pivot Seat Price: $5.46 |
| 11 |
63-8410 |
WASHER Price: $1.76 |
| 11 |
734117201 |
WASHER This part replaces 819131210. Price: $1.99 |
| 12 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 12 |
873680600 |
Nut, Crownlock 3/8-16 UNC Price: $1.99 |
| 13 |
104-1487 |
BOLT-CARR Price: $3.93 |
| 13 |
871110814 |
BOLT.HEX.BLACK This part replaces 874780814. Price: $3.99 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
810040800 |
Washer, Lock Hvy Helical Spring Price: $3.99 |
| 15 |
104-1440-03 |
SUPPORT-FAN Price: $395.73 |
| 15 |
819171912 |
Washer, 17/32 x 1 3/16 x 12 Ga. Price: $3.99 |
| 16 |
104-0006-03 |
LEVER-FAN, IDLER Price: $61.11 |
| 16 |
532127018 |
Bolt, Shoulder Price: $3.99 |
| 17 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 17 |
532121251 |
Strip, Foam Price: $5.46 |
| 18 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 18 |
98-3921 |
BELT Price: $16.95 |
| 19 |
532121248 |
Bushing, Snap Price: $3.99 |
| 19 |
95-3857 |
SCREW-HSBH Price: $4.09 |
| 20 |
532121250 |
Spring, Compression Price: $3.99 |
| 20 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 21 |
104-1447-03 |
BRACKET-FAN, SUPPORT Price: $39.88 |
| 21 |
532121249 |
Spacer, Split 28 Id. x .88 Lg. Price: $3.99 |
| 22 |
3274-12 |
SCREW-HSH Price: $0.81 |
| 22 |
532174648 |
Bracket Mounting Switch This part replaces 532121246. Price: $4.99 |
| 23 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 24 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 25 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 26 |
104-1481-03 |
BRACKET-MOUNT, FAN Price: $58.30 |
| 27 |
98-4561-03 |
SHIELD-ALTERNATOR Price: $56.98 |
| 29 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 31 |
33114-020 |
SCREW-HH Price: $0.28 |
| 32 |
322-4 |
SCREW-HH Price: $0.35 |
| 33 |
104-0007 |
SPACER Price: $39.26 |
| 34 |
322-3 |
SCREW-HH Price: $0.79 |
