Carburetor Assembly
Parts (33)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 125-3483 | BRUSH SHAFT ASM Price: $502.04 |
| 1 | 530058433 | Gasket-Insulator Price: $5.99 |
| 2 | 105-9635 | BRUSH-GROOMER Price: $200.88 |
| 2 | 530058431 | Adapter Price: $32.99 |
| 3 | 120-9657 | BOLT-J Price: $6.72 |
| 3 | 530058434 | Gasket Price: $15.68 |
| 4 | 233B0520 | Screw-Pan-WP Price: Call Us |
| 5 | 214B0616 | Screw-Pan Price: Call Us |
| 6 | 530058432 | Insulator Price: $24.99 |
| 7 | 110602388 | GASKET This part replaces 530058435. Price: $3.99 |
| 8 | 530058477 | Body Price: $6.99 |
| 9 | 140432051 | Filter Price: $2.99 |
| 10 | 921442308 | Spring This part replaces 530058449. Price: $2.99 |
| 11 | 920432094 | Pin Price: $1.99 |
| 12 | 160552051 | Lever This part replaces 530058453. Price: $2.99 |
| 13 | 530058450 | Screw Price: $4.12 |
| 14 | 160302078 | Valve-Float Price: $11.99 |
| 15 | 530058454 | Gasket Price: $7.99 |
| 16 | 530058455 | Diaphragm Price: $17.99 |
| 17 | 530058456 | Body Price: $99.99 |
| 18 | 490432067 | PRIMING PUMP This part replaces 530058457. Price: $6.99 |
| 19 | 530058458 | Cover-Primer Pump Price: $11.99 |
| 20 | 530058437 | Bracket Price: $32.99 |
| 21 | 530058459 | Screw Price: $3.99 |
| 22 | 920092277 | Screw "A" This part replaces 530058438. Price: $1.99 |
| 23 | 210832073 | Arm This part replaces 530058439. Price: $3.99 |
| 24 | 922002074 | Washer This part replaces 530058440. Price: $1.99 |
| 25 | 530058441 | Ring-Snap Price: $2.99 |
| 26 | 530058442 | Packing Price: $11.99 |
| 27 | 920552147 | O-Ring Price: $3.99 |
| 28 | 530058444 | Jet-Main #60 Price: $19.99 |
| 29 | 530058445 | Gasket Price: $14.99 |
| 30 | 430282067 | Diaphragm This part replaces 530058446. Price: $4.99 |
