| Ref | Part Number | Description |
|---|
| 2 |
532414555 |
KIT.CONTROL.DR.CASE.HALVES.GRY This part replaces 532195761. Price: $29.99 |
| 3 |
532187353 |
PULLEY.CAM.DRIVE.CONTROL.HV Price: $6.99 |
| 4 |
532425583 |
LEVER.SHORT.BLACK.EZ.WALK This part replaces 532190039. Price: $14.99 |
| 5 |
532414555 |
KIT.CONTROL.DR.CASE.HALVES.GRY This part replaces 532195762. Price: $29.99 |
| 6 |
532181698 |
SCREW, PHILLIPS HEAD 10 X 5/8 Price: $3.99 |
| 7 |
532400723 |
BRACKET.DRIVE.CONTROL.MOUNT.BL Price: $4.99 |
| 8 |
532186297 |
EZ WALK SNAP COVER PLATE Price: $5.99 |
| 9 |
532196002 |
CABLE.ASM.EZ.WALK Price: $44.99 |
| 10 |
532189074 |
DECAL.DRIVE.CONTROL.HV Price: $5.99 |
| 11 |
532188291 |
SPRING, TORSION Price: $3.99 |
| 12 |
532750634 |
SCREW Price: $2.99 |
| 13 |
532193354 |
TRANSMISSION.21.FWGD Price: $89.99 |
| 14 |
532193443 |
PULLEY.1.PIECE Price: $13.99 |
| 17 |
585802801 |
NUT.HEX.FL 5/16-18 TOP LCK BLK This part replaces 532166785. Price: $4.99 |
| 18 |
532168360 |
SPRING.SELECTOR.5/9POS This part replaces 532168599. Price: $3.99 |
| 19 |
532196401 |
KNOB.DELUXE.GRAY Price: $3.99 |
| 20 |
532407494 |
BRACKET.ADJ.5POS.ADS This part replaces 532165704. Price: $3.99 |
| 21 |
532160828 |
SHOULDER BOLT Price: $3.99 |
| 22 |
587070202 |
BEARING.SUPPORT.ASM This part replaces 532191039. Price: $12.99 |
| 23 |
532186578 |
ARM.ASM.AXLE.LR/RF.5/9POS.BZP This part replaces 532189278. Price: $7.99 |
| 24 |
532186577 |
ARM.ASM.AXLE.RR/LF.5/9POS.BZP This part replaces 532189277. Price: $8.99 |
| 25 |
532400783 |
COVER.DRIVE.21.RWGD.MO Price: $9.99 |
| 26 |
532750634 |
SCREW Price: $2.99 |
| 27 |
532183901 |
SPACER.34X1.38X.22 Price: $5.99 |
| 28 |
812000058 |
E-RING 7/16 RE Price: $2.99 |
| 29 |
581840401 |
COVER.DUST.WHEEL.INNER.WALK This part replaces 532189403. Price: $5.99 |
| 30 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 31 |
532175098 |
PAWL.DRIVE.21.EZ-WALK Price: $4.99 |
| 32 |
581009202 |
WHEEL.8X1.75.5SPK.RAD.3.GREY This part replaces 532400543. Price: $19.99 |
| 33 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 34 |
532175103 |
GEAR, PINION Price: $10.99 |
| 35 |
532175105 |
RETAINER.DRIVE.21.EZ-WALK.LT Price: $5.99 |
| 36 |
532175104 |
DISC.DRIVE.21.EZ-WALK Price: $5.99 |
| 37 |
532184172 |
SEAL.PINION Price: $5.99 |
| 38 |
532175102 |
RETAINER, DRIVE, RH Price: $5.99 |
| 40 |
532400542 |
WHEEL.8X1.75.GREY.RAD3.5SPOKE Price: $22.99 |
| 41 |
532414860 |
KIT.PINION.ASM This part replaces 532188330. Price: $76.99 |
| 43 |
532414860 |
KIT.PINION.ASM This part replaces 532188331. Price: $76.99 |
| 44 |
532183688 |
BELT.DRIVE.EZ.WALK.HI-VAC Price: $13.99 |
| 47 |
532067725 |
WASHER FLUT Price: $5.99 |
| 53 |
532187532 |
GEAR.24.TOOTH.WALK.MOWER Price: $11.99 |
| 54 |
532187533 |
SHAFT INPUT Price: $24.99 |
| 55 |
532183505 |
WIRE, FORMED (15966) Price: $5.99 |
| 56 |
532183506 |
BEARING Price: $5.99 |
| 57 |
532183508 |
SEAL.OUTPUT.SHAFT Price: $9.99 |
| 58 |
532183509 |
WASHER Price: $3.99 |
| 59 |
532183511 |
BUSHING Price: $4.99 |
| 60 |
532197385 |
RB OUTPUT.SHAFT.12246 Price: $37.99 |
| 61 |
532183513 |
SCREW Price: $3.99 |
