| Ref | Part Number | Description |
|---|
| 1 |
70-09-015 |
BATTERY Price: $137.52 |
| 2 |
70-01-340 |
BATTERY RETAINER W/ASSY Price: $50.28 |
| 3 |
ZBH1L045U |
HEX HD.BOLT M12*45 Price: $1.38 |
| 5 |
111-6791-03 |
BRACKET-MANIFOLD, CUTTER Price: $124.40 |
| 7 |
111-3110-03 |
BUMPER REAR WELDED ASSY Price: $184.47 |
| 8 |
65-07-051 |
BUSHING Price: $8.47 |
| 9 |
111-4668-03 |
CHASSIS-FRONT Price: $1,084.48 |
| 10 |
111-3509 |
ADAPTOR 3/8" BSP - T1FQLD Price: $15.31 |
| 11 |
ZNN1L000U |
HEX.NUT NYLOC M12 Price: $1.40 |
| 13 |
09441 |
NUT M8 NYL INSERT T TYPE Price: $1.39 |
| 14 |
111-2599-03 |
PLATE BATTERY MOUNT Price: $33.08 |
| 15 |
111-3217-03 |
PLATFORM SUPPORT FRONT LH Price: $53.28 |
| 16 |
111-2100-03 |
REAR CHASSIS W/A Price: $870.98 |
| 17 |
ZDH1L035U |
HEX.HD.SET SCW.M12*35 Price: $1.38 |
| 18 |
03162 |
STEEL BOLT Price: $1.39 |
| 19 |
09369 |
SETSCREW M8 X 30 Price: $1.40 |
| 20 |
09267 |
WASHER 5/16 X 7/8 X 15G GALV Price: $1.39 |
| 21 |
HY09485 |
WASHER M12 PLAIN Price: $1.40 |
| 22 |
111-3538 |
ADAPTOR 1/4" BSP M - T1FQLD Price: $14.71 |
| 23 |
ZWP1H000U |
WASHER (M8) Price: $1.40 |
| 24 |
111-6878 |
WHEEL ASM Price: $428.56 |
| 25 |
134-3969 |
HYD MOTOR ASM This part replaces 111-6761. Price: $1,936.17 |
| 26 |
111-3529 |
ADAPTOR 1/2" BSP M TO 8FQLH Price: $16.54 |
| 27 |
70-13-072 |
DECAL - JACKING POINT Price: $4.88 |
| 29 |
950832 |
DECAL Price: $5.78 |
| 30 |
70-09-171 |
TERMINAL Q R & VE Price: $13.80 |
| 31 |
122-1276 |
NEGATIVE BATTERY CABLE ASM This part replaces 70-09-172. Price: $75.81 |
| 32 |
111-3690 |
BATTERY CABLE +VE Price: $56.00 |
| 33 |
70-09-170 |
CABLE BATTERY - VE Price: $48.58 |
| 34 |
950889 |
DECAL WARNING HOT SURFACE Price: $22.13 |
| 35 |
111-3901 |
DECAL-TRANSMISSION, OIL Price: $4.30 |
| 36 |
111-9529 |
PLATE-SECURING Price: Call Us |
| 38 |
ZDH1L040U |
HEX.HD.SET SCW M12*40 Price: $1.31 |
| 41 |
ZNN1J000U |
HEX.NUT NYLOC M10 Price: $1.42 |
| 43 |
HY910808 |
STRIP - NEOPRENE Price: $15.11 |
| 46 |
09392 |
SETSCREW M10 X 30 HEX HD Price: $1.31 |
| 47 |
09479 |
WASHER M10 X 21 X 1.45 THK (P) Price: $1.39 |
| 48 |
ZNN1J000U |
HEX.NUT NYLOC M10 Price: $1.42 |
| 50 |
63-11-010 |
HEX HD.BOLT M12*40HT/10.9 Price: $6.59 |
| 51 |
111-4888-01 |
PLATE-LATCH, FRONT Price: $8.05 |
| 52 |
25-07-007 |
TENSION BUSH 30/25*50 LG Price: $14.47 |
| 53 |
111-4786 |
HYD CYLINDER ASM Price: $323.28 |
| 54 |
15-11-003 |
CARR.BOLT(8.8)M10*25 HT Price: $1.42 |
| 55 |
994560 |
PIN Price: $78.98 |
| 56 |
111-5300 |
SPACER-RAM Price: $12.62 |
| 59 |
09738 |
BOLT CARRIAGE Price: $1.42 |
| 60 |
111-5538-03 |
LOCATION-PLATE Price: $9.05 |
| 61 |
09599 |
WASHER Price: $1.42 |
| 62 |
111-7065-03 |
BRACE Price: $85.19 |
| 63 |
111-7094 |
BRACE-CHASSIS Price: $25.23 |
| 64 |
111-8008 |
PIN-ARM, ASM Price: $49.10 |
| 65 |
111-8007-03 |
PLATE-WEAR Price: $8.13 |
| 66 |
ZNN1X000U |
HEX.NUT M24 NYLOC Price: $5.40 |
