| Ref | Part Number | Description |
|---|
| 1 |
144925 |
SUB= 123899X Price: Call Us |
| 1 |
98-9462 |
ELEMENT-PUMP Price: $282.73 |
| 2 |
74760412 |
BOLT LT Price: Call Us |
| 2 |
98-9423 |
O-RING Price: $6.07 |
| 3 |
98-9443 |
PIN-JOINT Price: $13.13 |
| 4 |
98-9434 |
FLANGE-SLEEVE Price: $17.25 |
| 5 |
98-9421 |
VALVE-DELIVERY Price: $116.98 |
| 6 |
98-9424 |
SPRING-VALVE, DELIVERY Price: $21.66 |
| 7 |
98-9425 |
GASKET-VALVE, DELIVERY Price: $10.58 |
| 8 |
98-9447 |
O-RING Price: $18.23 |
| 9 |
98-9652 |
HOLDER-VALVE, DELIVERY Price: $111.74 |
| 10 |
98-9452 |
SCREW Price: $7.23 |
| 11 |
98-9422 |
TAPPET ASM Price: $275.51 |
| 12 |
98-9433 |
SHIM Price: $2.13 |
| 13 |
98-9429 |
SEAT-SPRING, LOWER Price: $50.60 |
| 14 |
98-9428 |
SPRING-PLUNGER Price: $32.36 |
| 15 |
98-9427 |
SEAT-SPRING, UPPER Price: $16.02 |
| 16 |
153664 |
SWITCH INTERLOCK Price: Call Us |
| 16 |
98-9432 |
SLEEVE-CONTROL Price: $107.77 |
| 17 |
98-9466 |
PLUG Price: $12.54 |
| 18 |
98-9451 |
GASKET Price: $1.92 |
| 19 |
10090400 |
SUB= 10040400 Price: Call Us |
| 19 |
98-9445 |
GASKET Price: $1.84 |
| 20 |
73350400 |
NUT Price: Call Us |
| 20 |
98-9464 |
BOLT-JOINT Price: $20.48 |
| 21 |
166181 |
HARNESS.ASM.LIGHT W/4152J Price: Call Us |
| 21 |
98-9446 |
GASKET Price: $2.50 |
| 22 |
4152J |
HEADLAMP BULB Price: Call Us |
| 22 |
98-9430 |
SCREW Price: $19.45 |
| 23 |
98-9643 |
INJECTION PUMP ASM This part replaces 98-9463. Price: $2,551.99 |
| 24 |
98-9465 |
PLATE Price: $9.73 |
| 25 |
165987 |
CABLE.BATTERY.CRD Price: Call Us |
| 25 |
98-9442 |
SCREW Price: $26.58 |
| 26 |
166180 |
FUSE.15 AMP Price: Call Us |
| 26 |
98-9426 |
PIN-GUIDE, TAPPET Price: $7.65 |
| 27 |
73510400 |
NUT Price: Call Us |
| 29 |
160784 |
SWITCH.PLUNGER Price: Call Us |
| 30 |
140301 |
SWITCH IGN 4POS Price: Call Us |
| 31 |
124211X |
NUT IGNITION Price: Call Us |
| 32 |
141226 |
COVER KEY SWITCH Price: Call Us |
| 33 |
122147X |
KEY Price: Call Us |
| 40 |
166158 |
HARNESS.IGN.CRD.ELECT Price: Call Us |
| 41 |
71110408 |
BOLT HXHD FIN Price: Call Us |
| 42 |
131563 |
SUB= 154336 Price: Call Us |
| 43 |
145673 |
SUB= 146154 Price: Call Us |
| 44 |
73640400 |
NUT HXKEP 1/4X20 Price: Call Us |
| 48 |
140844 |
ADAPTER AMMETER Price: Call Us |
| 50 |
154959 |
PTO SWITCH.BLK Price: Call Us |
| 51 |
140405 |
RING RETAIN PTO Price: Call Us |
| 52 |
141940 |
PROTECTION LOOP Price: Call Us |
| 58 |
165943 |
BUZZER CRD Price: Call Us |
| 59 |
166299 |
SWITCH.FBI.CRD Price: Call Us |
| 65 |
17211008 |
SCREW Price: Call Us |
| 66 |
17490608 |
SCREW LT Price: Call Us |
| 70 |
166668 |
HARNESS.ENGINE Price: Call Us |
| 80 |
146685 |
HARNESS.CLUT.EVX. Price: Call Us |
