| Ref | Part Number | Description |
|---|
| 1 |
221-551 |
Engine Price: Call Us |
| 1 |
427189 |
Reference Bar Price: Call Us |
| 2 |
36-3510 |
DISCONTINUED Price: Call Us |
| 2 |
486476 |
Operator Pad Price: Call Us |
| 3 |
3-0593 |
BRACKET Price: $28.44 |
| 3 |
463155 |
Operator Pad Assy., w/Decal Price: Call Us |
| 4 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 4 |
463015 |
Handlebar Assembly, LH Price: Call Us |
| 5 |
463016 |
Handlebar Assembly, RH Price: Call Us |
| 6 |
322-6 |
SCREW-HH Price: $0.45 |
| 6 |
481885-07 |
Knob, 5/16 - 18 Price: Call Us |
| 7 |
04201-17 |
Bolt, Hex 5/16" - .375 x 1.00- Stainless Steel Price: Call Us |
| 7 |
289-29 |
DISCONTINUED Price: Call Us |
| 8 |
04317-02 |
Locknut, 5/16-18 Flg. Elastic Stop - Stainless Steel Price: Call Us |
| 8 |
23-7410 |
DISCONTINUED Price: Call Us |
| 9 |
3290-153 |
DISCONTINUED Price: Call Us |
| 9 |
485842 |
Linkage Assy., Steering Price: Call Us |
| 10 |
2812-4 |
REDUCER-PIPE Price: $9.67 |
| 10 |
483453-14 |
Bearing, .625 ID Plastic Price: Call Us |
| 11 |
452957 |
Shaft Weldment, Control Arm Price: Call Us |
| 11 |
5-1077 |
KEY-SQUARE Price: $6.18 |
| 12 |
04220-04 |
Nut, 3/8 - 16 - Stainless Steel Price: Call Us |
| 12 |
3245-32 |
SCREW-HSH Price: $3.59 |
| 13 |
04201-30 |
Bolt, Hex Head 3/8 - 16 x 1.50 - Stainless Steel Price: Call Us |
| 13 |
244-58 |
PULLEY Price: $57.01 |
| 14 |
04108-02 |
Hex Head Socket, 5/16-18 x 1" (36) Price: Call Us |
| 14 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 15 |
04201-31 |
Bolt, Hex 3/8 - 16 x 1.75 - Stainless Steel Price: Call Us |
| 15 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 16 |
04203-29 |
Bolt, Carriage 3/8 - 16 x 1.25 - Stainless Steel Price: Call Us |
| 16 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 17 |
04317-03 |
Nut, Flange Elastic Stop 3/8 - 16 - Stainless Steel Price: Call Us |
| 17 |
3-0484 |
MOTOR MOUNT Price: $24.00 |
| 18 |
322-17 |
SCREW-HH Price: $2.62 |
| 18 |
453047 |
Bellcrank Weldment, Brake Price: Call Us |
| 19 |
452841 |
BRAKE PADDLE WLMT, LH Price: Call Us |
| 20 |
36-2320 |
DISCONTINUED Price: Call Us |
| 20 |
452842 |
Brake Paddle Weldment, RH Price: Call Us |
| 21 |
04241-07 |
Washer, Flat 5/8 - .687 x 1.00 x .078 - Stainless Steel Price: Call Us |
| 21 |
36-2330 |
MUFFLER ASM Price: $126.82 |
| 22 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 22 |
428529 |
Link, Brake Engage Price: Call Us |
| 23 |
452967 |
Lock Weldment, Neutral Price: Call Us |
| 24 |
483504 |
Bearing Price: Call Us |
| 25 |
48342 |
GRIP, PARKING BRAKE Price: Call Us |
| 26 |
463614 |
Brake Lever Assembly (Incl. #25) Price: Call Us |
| 27 |
04201-16 |
Bolt, Hex 5/16 - 18 x .75 - Stainless Steel Price: Call Us |
| 28 |
04230-03 |
Washer, Lock 5/16 Spring - Stainless Steel Price: Call Us |
| 29 |
04240-02 |
Washer, Flat 5/16 - .349 x .750 x .050 - Stainless Steel Price: Call Us |
| 30 |
04203-17 |
Bolt, Carriage 5/16 - 18 x 1" - - Stainless Steel Price: Call Us |
| 31 |
427908 |
Mounting Bracket, Brake Switch Price: Call Us |
| 32 |
483473 |
Switch, Double Pole - Plunger Price: Call Us |
| 33 |
04203-28 |
Bolt, Carriage 3/8-16 x 1.0 - Stainless Steel Price: Call Us |
| 34 |
48100-30 |
BUSHING, BRONZE - .376 ID X .627 OD Price: Call Us |
| 35 |
04208-01 |
Cap Screw, 3/8 - 16 x 1.25 Hex Socket - Stainless Steel Price: Call Us |
| 36 |
04201-07 |
Bolt, Hex 1/4 - 20 x 1.25 - Stainless Steel Price: Call Us |
| 37 |
04317-01 |
Locknut, 1/4 - 20 Flg. Elastic Stop - Stainless Steel Price: Call Us |
| 38 |
04241-06 |
Washer, Flat 5/16 - .349 x .750 x .050 - Stainless Steel Price: Call Us |
| 39 |
04224-02 |
Nut, Push On - Stainless Steel Price: Call Us |
| 40 |
04063-12 |
KEY, WOODRUFF #61, 3/16 X 5/8 Price: Call Us |
| 41 |
04212-01 |
Set Screw, 1/4 - 20 x .25 - Stainless Steel Price: Call Us |
| 42 |
481885-06 |
Knob, 5/16-18 Price: Call Us |
