| Ref | Part Number | Description |
|---|
| 1 |
114-3988 |
FAN DRIVE ASM This part replaces 74-5520. Price: $342.27 |
| 2 |
75-3780 |
FAN-ENGINE Price: $367.12 |
| 3 |
75-6380 |
SHAFT-FAN Price: $141.82 |
| 4 |
32121-2 |
PIN-ROLL, SLOTTED Price: $0.25 |
| 5 |
98-9313 |
PULLEY-FAN Price: $18.49 |
| 6 |
47-0110 |
SPACER-SPINDLE Price: $1.42 |
| 7 |
251-318 |
BEARING-BALL Price: $16.40 |
| 8 |
75-5310 |
SPACER-BEARING Price: $4.41 |
| 9 |
75-4450 |
HUB Price: $205.03 |
| 10 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 11 |
67-1630 |
SPACER Price: $28.84 |
| 12 |
323-6 |
SCREW-HH Price: $0.66 |
| 13 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 14 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 15 |
98-9322 |
SCREW-HSH Price: $4.89 |
| 16 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 17 |
98-4598 |
CABLE-BATTERY, NEGATIVE Price: $69.78 |
| 18 |
110-0035 |
KIT-ENGINE, KUBOTA DSL This part replaces 98-9300. Price: $8,164.44 |
| 19 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 20 |
3256-78 |
WASHER-FLAT Price: $1.21 |
| 21 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 22 |
48-7890 |
NUT-HEX Price: $0.25 |
| 23 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 24 |
57-6390 |
NUT-JAM Price: $0.89 |
| 25 |
98-4515-03 |
BRACKET-REAR ENGINE, LH This part replaces 98-4515. Price: $62.07 |
| 26 |
94-4514 |
PIN-LOCK, TILT Price: $35.83 |
| 27 |
323-12 |
SCREW-HH Price: $1.14 |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 29 |
87-5100 |
WASHER-SNUBBING Price: $3.46 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 31 |
43-0090 |
SCREW-HH Price: $8.05 |
| 32 |
48-9590 |
WASHER-LOCK This part replaces 42-9600. Price: $0.25 |
| 33 |
323-10 |
SCREW-HH Price: $0.89 |
| 34 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 35 |
33114-016 |
SCREW-HH Price: $0.27 |
| 36 |
98-4596 |
WASHER-MOUNT, ENGINE Price: $20.72 |
| 37 |
121-9076 |
MOUNT-ENGINE This part replaces 83-1030. Price: $37.76 |
| 38 |
322-6 |
SCREW-HH Price: $0.45 |
| 39 |
98-4539-03 |
BRACKET-ENGINE MOUNT, LH This part replaces 98-4539. Price: $179.96 |
| 40 |
98-4543-03 |
BRACKET-ENGINE MOUNT, RH This part replaces 98-4543. Price: $180.69 |
| 41 |
98-4530-03 |
SUPPORT-FAN This part replaces 98-4530. Price: $349.24 |
| 42 |
98-4575-03 |
LEVER-IDLER, FAN This part replaces 98-4575. Price: $43.57 |
| 43 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 44 |
98-9312 |
V-BELT Price: $28.51 |
| 45 |
323-7 |
SCREW-HH Price: $0.65 |
| 46 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 47 |
98-4560 |
DISCONTINUED Price: Call Us |
| 48 |
98-9738 |
BRACKET - FAN, SUPPORT This part replaces 98-4577. Price: $29.77 |
| 49 |
322-2 |
SCREW-HH Price: $0.69 |
| 50 |
321-4 |
SCREW-HH Price: $0.99 |
| 51 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 52 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 53 |
322-4 |
SCREW-HH Price: $0.35 |
| 54 |
98-4547 |
PLATE-MOUNT, FAN Price: $20.17 |
| 55 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 56 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 57 |
98-9333 |
DISCONTINUED Price: Call Us |
| 58 |
98-4513-03 |
BRACKET-ENGINE, REAR This part replaces 98-4513. Price: $78.69 |
| 59 |
93-0095-03 |
BRACKET-ENGINE, FRONT This part replaces 93-0095. Price: $111.93 |
| 60 |
3213-2 |
SCREW-HH Price: $1.90 |
| 61 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 62 |
3256-40 |
WASHER-FLAT Price: $2.10 |
| 63 |
98-4561-03 |
SHIELD-ALTERNATOR This part replaces 98-4561. Price: $56.98 |
| 64 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 65 |
98-4510 |
HOSE-CLEANNER, AIR Price: $62.66 |
