| Ref | Part Number | Description |
|---|
| 1 |
09735A |
ROD-CONNEC Not Available Price: |
| 2 |
983-0029A-0637 |
PIVOT LINK (LH) Not Available This part replaces 17640. Price: |
| 3 |
17641 |
PIVOT LINK ASS'Y. (RH) Not Available Price: |
| 4 |
17710 |
DECK HANGER LINK ASS'Y Not Available Price: |
| 5 |
14800A |
HANGER-DECK LINK Not Available Price: |
| 6 |
14804A |
DECK HANGER LINK ASS'Y Not Available Price: |
| 7 |
948-0331 |
SPACER Not Available This part replaces 748-0331. Price: |
| 8 |
736-0231 |
Fl-Wash. .344" l.D. x 1.125" Price: $4.02 |
| 11 |
783-0014 |
EXTENSION-HITCH Not Available Price: |
| 12 |
714-0470 |
Cotter Pin 1/8" Dia. Price: $3.90 |
| 13 |
936-0256 |
Fl-Wash. This part replaces 736-0256. Price: $6.24 |
| 16 |
710-0604A |
Screw, 5/16-18 x .625 This part replaces 710-0604. Price: $3.96 |
| 17 |
748-0176 |
Flange Brg. .63" I.D. Price: $8.54 |
| 18 |
710-0650 |
Hex Wash. TT-Tap Scr. 5/16-18 x .875" Lg. Price: $3.71 |
| 19 |
710-0118 |
Hex Bolt 5/16-18 x .75" Lg. Price: $3.76 |
| 20 |
783-04113P |
Index Brkt. This part replaces 17730. Price: $22.39 |
| 21 |
17830 |
Upper Frame - R.H. Price: Call Us |
| 23 |
736-0267 |
FLAT WASHER .38X.88 Price: $3.90 |
| 24 |
736-0160 |
Fl-Wash. .531" I.D. x .93" O.D. Price: $3.90 |
| 26 |
738-0526 |
ROD-RUNNING BOARD Not Available Price: |
| 27 |
710-0351 |
Truss Mach. Scr. #10 x .5" Lg. Price: $3.90 |
| 28 |
14802A-0637 |
DECK LIFT LINK (POWDER BLACK) Not Available This part replaces 14802A. Price: |
| 29 |
911-0723A |
FERRULE 3/8-24 x .375 x 1.31 LG Not Available This part replaces 711-0723A. Price: |
| 30 |
17712-0637 |
Adj. Deck Lift Link This part replaces 17712. Price: $22.73 |
| 31 |
912-3066 |
Hex Nut 1/2-20 Grade 5 This part replaces 712-3066. Price: $6.01 |
| 32 |
911-0841 |
LIFT ADJUSTMENT LINKER Not Available This part replaces 711-0841. Price: |
| 33 |
17825A |
LIFT SHAFT ASS'Y. Not Available Price: |
| 34 |
725-0803B |
Safety Switch This part replaces 725-0803C. Price: $29.83 |
| 35 |
714-0145 |
Inter. Cotter Pin 3/8" Dia. Price: $4.42 |
| 36 |
732-0648 |
EXTENSION SPRING Not Available Price: |
| 37 |
17636D-0637 |
STABILIZER BRACKET BLACK Not Available This part replaces 17636A. Price: |
| 38 |
738-0670A |
SHAFT .50 DIA x 10.50 LG Not Available This part replaces 738-0670. Price: |
| 39 |
732-0638 |
EXTENSION SPRING Not Available Price: |
| 40 |
720-0233 |
LIFT HANDLE GRIP Not Available Price: |
| 41 |
17675 |
DECK LIFT HANDLE ASS'Y Not Available Price: |
| 42 |
738-0669 |
ROD .380 DIA x 9.34"L Not Available Price: |
| 43 |
747-0598 |
Disengagement Rod Price: $12.21 |
| 44 |
97624-0637 |
SHAFT ASSY (POWDER BLACK) Not Available This part replaces 17624. Price: |
| 45 |
932-0556 |
Ext. Spring .94" O.D. x 7.58" This part replaces 732-0556. Price: $20.03 |
| 46 |
17831 |
Upper Frame - L.H. Price: Call Us |
| 47 |
741-0487C |
Flange Bearing .632 ID This part replaces 741-0313. Price: $6.87 |
| 48 |
171284 |
Spring Retainer Brkt. Price: Call Us |
| 49 |
712-3019 |
Hex Nut 7/16-14 Thd. (Gr. 5) Price: $5.94 |
| 50 |
710-0505 |
Hex Bolt 7/16-14 x 1" Lg. Price: $6.01 |
| 51 |
736-0439 |
BELL WASHER .460X1.13X.062 Not Available Price: |
