CARBURETOR
Parts (39)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 3290-378 | TIE-CABLE Price: $0.79 |
| 2 | 574012501 | RP_SCREEN (RPLS 331081380) This part replaces 520957001. Price: $3.99 |
| 2 | 93-1672 | SHIELD-PULLEY Price: $28.77 |
| 3 | 577806901 | COVER Price: $11.99 |
| 3 | 93-1673 | SHIELD-PULLEY Price: $20.91 |
| 4 | 120-9738 | SCREW-HH This part replaces 322-11. Price: $0.84 |
| 4 | 520976301 | SCREW Price: $2.99 |
| 5 | 3253-4 | WASHER-LOCK Price: $0.25 |
| 5 | 520954801 | GASKET Price: $9.99 |
| 6 | 3256-23 | WASHER-PLAIN Price: $0.28 |
| 6 | 596968101 | PUMPS Price: $8.99 |
| 7 | 521085401 | VALVE INLET Price: $11.99 |
| 7 | 93-1671 | TUBE - SPACER Price: $9.91 |
| 8 | 516972101 | GASKET Price: $4.99 |
| 8 | 93-1669 | SHIELD - MUFFLER *B Price: $533.16 |
| 9 | 577807001 | DIAPHRAGM Price: $14.99 |
| 10 | 514189201 | COVER Price: $6.99 |
| 11 | 578895401 | SPRING Price: $3.99 |
| 12 | 578913101 | NEEDLE H Price: $17.99 |
| 13 | 578913001 | CAP LIMITER Price: $8.99 |
| 14 | 577807101 | SCREW Price: $2.99 |
| 15 | 520977401 | PIN Price: $4.99 |
| 16 | 577807201 | LEVER Price: $1.99 |
| 17 | 578895501 | SHAFT ASSY THROTTLE Price: $11.99 |
| 18 | 513593201 | SPRING Price: $4.99 |
| 19 | 577815701 | SCREW, IDLE Price: $8.99 |
| 20 | 514251901 | VALVE, THROTTLE Price: $7.99 |
| 21 | 520759801 | SCREW Price: $2.99 |
| 25 | 505056501 | E-RING Price: $3.99 |
| 26 | 577815801 | LEVER THROTTLE Price: $3.99 |
| 27 | 577815501 | SPRING Price: $3.99 |
| 28 | 514243301 | CHOKE SPRING Price: $5.99 |
| 29 | 514242601 | BALL Price: $5.99 |
| 30 | 593172101 | NEEDS DESCRIPTION Price: Call Us |
| 31 | 579367101 | VALVE CHOKE Price: $6.99 |
| 33 | 520978801 | SCREW ASSY Price: $2.99 |
| 34 | 578912901 | NEEDLE L Price: $14.99 |
| 35 | 516524201 | WASHER Price: $2.99 |
| 36 | 513400801 | SWIVEL Price: $11.99 |
