| Ref | Part Number | Description |
|---|
| 1 |
67-3990 |
LEVER ASSEMBLY Price: $41.40 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 2 |
67-4000 |
DISCONTINUED Price: Call Us |
| 3 |
67-4270 |
BOLT Price: $0.89 |
| 4 |
67-4130 |
GOVERNOR COVER Price: $102.33 |
| 5 |
67-4160 |
GASKET Price: $4.78 |
| 6 |
42-8830 |
O-RING Price: $2.96 |
| 7 |
75-4980 |
GOVERNOR SPRING LEVER Price: $8.05 |
| 8 |
67-3260 |
WASHER Price: $1.58 |
| 9 |
42-9640 |
JAM NUT Price: $4.69 |
| 10 |
42-8830 |
O-RING Price: $2.96 |
| 11 |
67-4140 |
LEVER ASSEMBLY Price: $76.30 |
| 12 |
42-9430 |
SCREW-HH Price: $0.30 |
| 13 |
67-4040 |
WEIGHT ASSEMBLY Price: $98.67 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 15 |
67-4010 |
STOPPER Price: $17.87 |
| 16 |
67-4070 |
SLIDING SHAFT ASSEMBLY Price: $206.32 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 17 |
67-4280 |
DISCONTINUED Price: Call Us |
| 18 |
67-4060 |
LEVER Price: $145.19 |
| 19 |
67-4050 |
SHAFT Price: $30.29 |
| 20 |
67-5040 |
DISCONTINUED Price: Call Us |
| 21 |
67-4090 |
LEVER Price: $52.49 |
| 22 |
70-8720 |
TIE ROD SPRING Price: $9.09 |
| 23 |
107-1581 |
TIE ROD ASM This part replaces 67-4030. Price: $82.44 |
| 24 |
107-1581 |
TIE ROD ASM This part replaces 67-4080. Price: $82.44 |
| 25 |
75-4990 |
GOVERNOR SPRING Price: $7.67 |
| 26 |
67-4210 |
TORQUE SPRING CASE Price: $22.42 |
| 27 |
67-4230 |
STOPPER Price: $25.34 |
| 28 |
67-4190 |
DISCONTINUED Price: Call Us |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 29 |
67-4220 |
DISCONTINUED Price: Call Us |
| 30 |
67-4200 |
SPECIAL NUT Price: $5.71 |
| 31 |
67-4180 |
DISCONTINUED Price: Call Us |
| 32 |
43-2820 |
SEALING CAP Price: $11.21 |
| 33 |
42-9420 |
DISCONTINUED Price: Call Us |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
67-4290 |
NUT Price: $0.91 |
| 35 |
596874801 |
Rods This part replaces 532401031. Price: $6.99 |
| 35 |
67-4120 |
PIN Price: $1.25 |
| 37 |
42-8690 |
SEAL METAL MK99200001 Price: $3.26 |
| 38 |
42-8700 |
WIRE Price: $6.33 |
| 40 |
67-4150 |
STOP LEVER Price: $18.57 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 99 |
532415742 |
ROD.SPRING.BYPASS.K46.LT.Z Price: $7.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532413430 |
KEEPER.CENTER SPAN.1.688 Price: $5.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532411484 |
HANDLE.PARKNG BRK.PRED.LT.428 This part replaces 532441407. Price: $24.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
585658602 |
Stop This part replaces 585658601. Price: $4.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 230 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 231 |
532407287 |
IDLER.V-GROOVE.1.688.OFFSET Price: $19.99 |
| 325 |
586431203 |
BRACKET TORQUE STRAP This part replaces 586431202. Price: $4.99 |
| 326 |
586001103 |
BRACKET TORQUE STRAP This part replaces 586001102. Price: $5.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
