| Ref | Part Number | Description |
|---|
| 1 |
322-3 |
SCREW-HH Price: $0.79 |
| 2 |
75-9260-03 |
RESERVOIR SUPPORT This part replaces 75-9260. Price: $124.08 |
| 3 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 4 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 5 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
62-5330-03 |
SIDE PANEL/BRACE ASM This part replaces 62-5330. Price: $51.05 |
| 8 |
32128-44 |
NUT Price: $2.69 |
| 9 |
3230-15 |
SCREW-CARR Price: $1.49 |
| 10 |
92-3189 |
INSTR. PANEL WA *B Price: $153.86 |
| 11 |
321-11 |
SCREW-HH Price: $0.36 |
| 12 |
3256-70 |
WASHER-FLAT Price: $0.25 |
| 13 |
323-9 |
SCREW-HH This part replaces 322-45. Price: $1.29 |
| 14 |
85-5330-01 |
PLATE-SEAT ASM This part replaces 85-5330. Price: $88.55 |
| 15 |
32128-25 |
NUT-HF Price: $3.19 |
| 16 |
61-3840 |
DISCONTINUED Price: Call Us |
| 17 |
237-37 |
BUMPER-RUBBER Price: $4.33 |
| 18 |
93-6868-03 |
STEP-FOOT This part replaces 83-9730. Price: $438.49 |
| 19 |
72-4350 |
DISCONTINUED Price: Call Us |
| 20 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 21 |
37-9590 |
DISCONTINUED Price: Call Us |
| 22 |
218-461 |
NUT-HH Price: $2.50 |
| 23 |
323-7 |
SCREW-HH This part replaces 322-43. Price: $0.65 |
| 24 |
237-7 |
O-RING Price: $8.82 |
| 25 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 26 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 27 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 28 |
27-9870 |
PIN-SWITCH, SEAT Price: $31.55 |
| 29 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 30 |
43-8610 |
GUIDE Price: $23.35 |
| 31 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 32 |
237-30 |
O-RING Price: $2.50 |
| 33 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 34 |
88-9550 |
DISCONTINUED Price: Call Us |
| 35 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 36 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 37 |
2412-71 |
CLAMP-R Price: $6.11 |
| 38 |
3290-196 |
NUT Price: $7.79 |
| 39 |
62-7170 |
SPACER-RUBBER Price: $28.36 |
| 40 |
3290-199 |
NUT-SPEED Price: $4.09 |
| 41 |
76-0500-03 |
COVER-RESERVOIR SUPT This part replaces 76-0500. Price: $30.56 |
| 42 |
92-3180-01 |
PANEL This part replaces 92-3180. Price: $252.85 |
| 43 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 44 |
83-9550 |
DECAL-WARNING Price: $12.60 |
| 45 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 46 |
2412-133 |
CLAMP-R Price: $3.19 |
| 47 |
28-6180 |
PIN-PEDAL Price: $5.05 |
| 48 |
85-5340 |
TUBE-PIVOT, SEAT Price: $5.84 |
| 49 |
32122-14 |
SCREW-PPH Price: $1.02 |
| 50 |
80-3940 |
DISCONTINUED Price: $2.00 |
| 51 |
237-88 |
GROMMET Price: $2.96 |
| 52 |
61-3880-01 |
RH ACCESS PANEL This part replaces 61-3880. Price: $109.91 |
| 53 |
85-5230 |
BRACKET-PIVOT, SEAT Price: $9.78 |
| 54 |
3229-11 |
SCREW-CARR This part replaces 3229-22. Price: $0.99 |
| 55 |
32128-33 |
NUT-HF Price: $0.25 |
| 56 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 57 |
32148-8 |
NUT-CLINCH Price: $2.31 |
| 501278201 |
501278201 |
WASHER Price: $3.99 |
| 503227201 |
503227201 |
NUT Price: $2.99 |
| 503443201 |
591375401 |
KIT FUEL FILTER This part replaces 503443201. Price: $8.99 |
| 503735801 |
503735801 |
FUEL TANK BUSHING Price: $5.99 |
| 503828004 |
503828004 |
FUEL CAP Price: $9.99 |
| 503840002 |
503840002 |
CRANKCASE Price: $89.99 |
| 503988101 |
503988101 |
BOLT Price: $3.99 |
| 537042403 |
537042403 |
FUEL HOSE/127MM Price: $4.99 |
| 537042404 |
581756114 |
FUEL HOSE This part replaces 537042404. Price: $4.99 |
