| Ref | Part Number | Description |
|---|
| 1 |
322-6 |
SCREW-HH Price: $0.45 |
| 1 |
532184233 |
DECK.SVC.4.GA.WHLS.48".BLK This part replaces 532183389. Price: $349.99 |
| 2 |
32151-73 |
RING-CLIP Price: $2.59 |
| 3 |
140-6248 |
DAMPER This part replaces 76-8870. Price: $159.54 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 4 |
323-7 |
SCREW-HH Price: $0.65 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 5 |
92-7761 |
DISCONTINUED Price: Call Us |
| 6 |
237-161 |
O-RING Price: $6.06 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 7 |
86-5590 |
DISCONTINUED Price: Call Us |
| 8 |
3213-2 |
SCREW-HH Price: $1.90 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 9 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 10 |
84-1380-03 |
ANCHOR-SPRING This part replaces 84-1380. Price: $75.43 |
| 11 |
32144-26 |
SCREW-FLOW, TAPTITE Price: $5.75 |
| 12 |
76-9430-03 |
SPRING-EXTENTION This part replaces 76-9430. Price: $28.14 |
| 13 |
532175147 |
SHAFT, ASM. MANDEREL SEALED Price: $24.99 |
| 13 |
84-1480 |
HOSE-DAMPENER Price: $12.04 |
| 14 |
323-29 |
SCREW-HH Price: $0.42 |
| 14 |
532174358 |
HOUSING, MANDREL 48" Price: $49.99 |
| 15 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
596987501 |
Bolts This part replaces 872110610. Price: $3.99 |
| 17 |
63-8410 |
WASHER Price: $1.76 |
| 18 |
3296-9 |
NUT-HEX Price: $0.25 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
322-10 |
SCREW-HH Price: $0.70 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
531167501 |
SERVICE KIT BAFFLE BAFFLE This part replaces 532174378. Price: $12.99 |
| 20 |
82-5180-03 |
CONTROL-PUMP This part replaces 82-5180. Price: $134.08 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
63-9751 |
DISCONTINUED Price: Call Us |
| 22 |
88-1470 |
DISCONTINUED Price: Call Us |
| 23 |
86-3020 |
DISCONTINUED Price: Call Us |
| 24 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 27 |
532180655 |
DEFLECTOR.ASM.BLACK.48" This part replaces 532181707. Price: $39.99 |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 28 |
82-5280 |
SHAFT-PIVOT Price: $51.63 |
| 29 |
251-259 |
BEARING-BALL Price: $13.67 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
322-7 |
SCREW-HH Price: $0.89 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 32 |
84-0750 |
DISCONTINUED Price: Call Us |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 33 |
86-5940 |
SPACER-BEARING, UPPER Price: $5.16 |
| 34 |
323-47 |
SCREW-HH Price: $1.22 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 36 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 36 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 37 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 38 |
100-2592 |
SCREW-HHF This part replaces 66-9303. Price: $9.09 |
| 39 |
532174375 |
PULLEY.DRIVEN.DECK.48' Price: $34.99 |
| 39 |
86-3040 |
COUPLER-LINE, DRIVE Price: $381.88 |
| 40 |
253-43 |
SEAL-OIL Price: $31.16 |
| 41 |
84-1330 |
DISCONTINUED Price: Call Us |
| 42 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 43 |
532174373 |
ARM, IDLER SECONDARY Price: $9.99 |
| 43 |
84-1030 |
DISCONTINUED Price: Call Us |
| 44 |
84-0170-03 |
PULLEY-PTO This part replaces 84-0170. Price: $874.74 |
| 45 |
251-314 |
BEARING-BALL Price: $102.23 |
| 45 |
532180806 |
COVER.MANDREL.DECK.48" Price: $12.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 46 |
86-2830-03 |
PLATE-ADAPTER, MAIN This part replaces 86-2830. Price: $409.90 |
| 47 |
532180808 |
V-BELT, 48"SECONDARY Price: $49.99 |
| 47 |
88-1440 |
WASHER-LOCK Price: $14.32 |
| 48 |
532174368 |
V-BELT PRIMARY 48" Price: $49.99 |
| 48 |
88-1430 |
LOCKNUT-BEARING Price: $30.40 |
| 49 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 49 |
839000600 |
Nut, Lock 3/8-16 unc Price: Call Us |
| 50 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 50 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 51 |
92-2581 |
DISCONTINUED Price: Call Us |
| 52 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 52 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 53 |
75-5470 |
SPACER-BEARING Price: $3.06 |
| 54 |
3220-3 |
NUT-HJ Price: $0.28 |
| 54 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 55 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 55 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 56 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 56 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL Price: $17.99 |
| 57 |
3290-477 |
WASHER-CURVED Price: $0.79 |
| 57 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 58 |
324-4 |
SCREW-HH Price: $0.95 |
| 59 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 60 |
84-1500 |
DISCONTINUED Price: Call Us |
| 61 |
82-5240-03 |
PIVOT PLATE This part replaces 82-5240. Price: $13.33 |
| 62 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 63 |
76-9760 |
DAMPER-PIVOT Price: $96.95 |
| 64 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 65 |
80-7730 |
SPACER Price: $1.97 |
| 66 |
92-1351 |
DISCONTINUED Price: Call Us |
| 72 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 91 |
529846201 |
SERVICE KIT BRKT.NOSEROLLER.RH This part replaces 532180535. Price: $5.99 |
| 92 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 94 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 95 |
529846101 |
SERVICE KIT BRKT.NOSEROLLER.LH This part replaces 532180534. Price: $5.99 |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
532179479 |
SPRING PRIMARY DRIVE Price: $3.99 |
| 99 |
532193195 |
PULLEY.V.IDLER This part replaces 532184058. Price: $49.99 |
| 100 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 110 |
532175016 |
ARM, SPRING SECONDARY Price: $4.99 |
| 111 |
532174610 |
ARM SPRING FIXED TENSION Price: $6.99 |
| 113 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 116 |
596434404 |
Bolts This part replaces 532184219. Price: $4.99 |
| 117 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 121 |
532174371 |
SPRING.DRIVE.SECONDARY.48".DEC Price: $5.99 |
| 126 |
532174372 |
ARM, IDLER PRIMARY DECK Price: $9.99 |
| 130 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 131 |
819131606 |
Washer 13/32 x 1 x 6 Ga. Price: $4.99 |
| 132 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 182 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 183 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 184 |
532173979 |
KEEPER BELT IDLER PLATED Price: $4.99 |
