| Ref | Part Number | Description |
|---|
| 1 |
99-5610 |
PIN Price: $40.16 |
| 2 |
98-1880-03 |
KNUCKLE-PIVOT Price: $350.23 |
| 3 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 4 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 5 |
100-4872 |
PLATE-SWITCH, NEUTRAL Price: $11.84 |
| 6 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 7 |
104-1450 |
BOLT-CARR Price: $0.25 |
| 8 |
94-9998 |
WASHER-THRUST Price: $11.60 |
| 9 |
94-9974 |
RING-RETAINING Price: $0.70 |
| 10 |
105-3359 |
NO. 4 LIFT ARM ASM Price: $923.86 |
| 11 |
75-5350 |
PIN-SLIDE, CYLINDER Price: $41.31 |
| 12 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 13 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 14 |
105-7948 |
HYD HOSE ASM Price: $226.47 |
| 15 |
105-7945 |
HYD HOSE ASM Price: $221.15 |
| 16 |
105-3347-03 |
FRAME-CARRIER, FRONT Price: $1,726.31 |
| 17 |
328-7 |
SCREW-HH Price: $4.00 |
| 18 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 20 |
105-0110 |
NO. 5 LIFT ARM ASM Price: $912.87 |
| 21 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 22 |
33114-020 |
SCREW-HH Price: $0.28 |
| 23 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 24 |
99-5621 |
GUIDE-HOSE Price: $34.45 |
| 25 |
125-1906 |
PIN-CYLINDER This part replaces 105-9889. Price: $27.84 |
| 26 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 27 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 28 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 29 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 30 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 31 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 32 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 33 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 34 |
105-7947 |
HYD HOSE ASM Price: $217.43 |
| 35 |
100-1270 |
SWITCH-PROXIMITY Price: $96.57 |
| 36 |
110-9709 |
HYD CYLINDER ASM This part replaces 99-6986. Price: $743.86 |
| 37 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 38 |
108-6715 |
GAUGE BAR ASM This part replaces 98-1852. Price: $148.12 |
| 43 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 44 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 45 |
32128-43 |
NUT-FLANGE Price: $0.94 |
