| Ref | Part Number | Description |
|---|
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 1 |
532180375 |
KIT.RAIL.CHASS.RH.GT This part replaces 532180372. Price: $59.99 |
| 2 |
532175282 |
DRAWBAR, GT Price: $59.99 |
| 2 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 3 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 4 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 4 |
873680700 |
Nut, Crown Lock 7/16-14 Unc Price: $2.99 |
| 5 |
583716201 |
DASH.STEALTH YTGT.2CYL.BLK 428 This part replaces 532177582. Price: $34.99 |
| 5 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 6 |
532157882 |
DASH VGT, LOWER Price: $29.99 |
| 6 |
82-9850-03 |
AXLE-REAR Price: $1,614.33 |
| 7 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 7 |
93-0311-03 |
SPINDLE-WHEEL, LH This part replaces 93-0311-01. Price: $378.60 |
| 8 |
532145166 |
SUPPORT, BATTERY Price: $4.69 |
| 8 |
69-2990 |
STUD-WHEEL Price: $4.85 |
| 9 |
117-8969 |
HUB ASM This part replaces 69-2960-03. Price: $336.24 |
| 10 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 11 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 12 |
69-9880 |
TIRE (23X10.5-12) 6-PLY Price: $189.93 |
| 13 |
23-7270 |
NUT-LUG Price: $10.37 |
| 14 |
217-116 |
WHEEL Price: $258.19 |
| 14 |
532194976 |
HOOD.ASM.PNT This part replaces 532177583. Price: $99.99 |
| 15 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 15 |
583125201 |
KIT.HARNESS/LIGHT ASM DUAL This part replaces 532161842. Price: $109.99 |
| 16 |
532121794 |
COVER ACCESS Price: $3.99 |
| 16 |
69-2970 |
CAP-HUB Price: $20.74 |
| 17 |
3220-7 |
NUT-JAM Price: $4.09 |
| 17 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 18 |
532182873 |
GRILLE.STEALTH P/L.YTGT.GREY This part replaces 532177584. Price: $169.99 |
| 18 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 19 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 19 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 20 |
254-107 |
CUP-BEARING, TAPERED Price: $9.93 |
| 20 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 21 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 21 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 22 |
69-2980 |
SEAL Price: $33.94 |
| 23 |
110-6141-03 |
RH TIE ROD END ASM This part replaces 2116-4. Price: $148.18 |
| 24 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 24 |
532182508 |
FOOTREST.RH.BLACK This part replaces 532181058. Price: $22.99 |
| 25 |
2412-7 |
CLAMP ASM Price: $23.32 |
| 25 |
583125201 |
KIT.HARNESS/LIGHT ASM DUAL This part replaces 532161841. Price: $109.99 |
| 27 |
110-9719-03 |
TIE ROD ASM This part replaces 82-9260. Price: $380.21 |
| 28 |
532182507 |
FOOTREST.LH.BLACK This part replaces 532181057. Price: $37.99 |
| 29 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 30 |
32136-2 |
NUT-SHH Price: $3.55 |
| 30 |
532145052 |
SADDLE.HYDRO.95 Price: $4.99 |
| 31 |
32136-13 |
NUT-SHH Price: $2.85 |
| 31 |
532161419 |
BRACKET SUPT 1-PC VGT STEERING Price: $3.99 |
| 32 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 32 |
532161327 |
BRACKET Price: $5.99 |
| 33 |
48-6640 |
BEARING Price: $10.04 |
| 33 |
532161326 |
BRACKET. Price: $3.99 |
| 34 |
48-6660 |
WASHER Price: $5.22 |
| 34 |
532177018 |
PLATE ASM ENG CHASSIS Price: $32.99 |
| 35 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 35 |
98-7414 |
HOSE-HYD Price: $84.76 |
| 36 |
115-8014 |
CYLINDER-HYDRAULIC This part replaces 77-4800. Price: $1,015.97 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532196023 |
KIT FENDER.YTGT.W/S.ORANGE This part replaces 532181720. Price: $159.99 |
| 37 |
98-7415 |
HOSE-HYD Price: $72.36 |
| 38 |
237-22 |
O-RING Price: $2.43 |
| 39 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 39 |
532175278 |
BRACKET AXLE, FRONT Price: $9.99 |
| 40 |
237-78 |
O-RING Price: $3.85 |
| 41 |
60-3670 |
PIN Price: $12.56 |
| 42 |
82-9210 |
SHAFT-PIVOT Price: $187.73 |
| 43 |
532136939 |
FRONT SUSPENSION BRKT LH Price: $12.99 |
| 44 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 44 |
532136940 |
FRONT SUSPENSION BRKT RH Price: $12.99 |
| 45 |
106-6895-03 |
BALL JOINT ASM This part replaces 69-9810-03. Price: $258.08 |
| 45 |
532176018 |
BRACKET, ASM., SUSP CHASSIS RH Price: $9.99 |
| 47 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 47 |
93-0310-03 |
SPINDLE-WHEEL, RH This part replaces 93-0310-01. Price: $584.69 |
| 48 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 49 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 50 |
532175476 |
BRACKET, CHASSIS FRONT Price: $14.99 |
| 50 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 51 |
340-54 |
ELBOW-45 DEG Price: $40.72 |
| 56 |
532176016 |
BRACKET ASM., SUSP CHASSIS LH Price: $9.99 |
| 58 |
532183569 |
BRACKET ASM., FENDER This part replaces 532175315. Price: $9.99 |
| 60 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 86 |
596238601 |
Bolts This part replaces 874760716. Price: $2.99 |
| 90 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 91 |
532180366 |
FRAME RAIL LH Price: $48.99 |
| 99 |
532177143 |
ROD ASM, BYPASS Price: $22.99 |
| 122 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 Price: $3.99 |
| 130 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532164863. Price: $14.99 |
| 138 |
532181798 |
CUPHOLDER Price: $5.99 |
| 139 |
532171873 |
BOLT, SHOULDER 5/16-18 Price: $4.99 |
| 140 |
532163806 |
MAGNET STEALTH Price: $7.27 |
| 141 |
532163805 |
STRIKER PLATE Price: $4.99 |
| 142 |
532161897 |
BRACKET DASH STEALTH(R) Price: $5.99 |
| 143 |
532177586 |
SKIRT GRILLE RH Price: $37.99 |
| 144 |
532161900 |
BRACKET DASH STEALTH LH Price: $5.99 |
| 146 |
532177587 |
SKIRT GRILLE LH Price: $23.99 |
| 148 |
532164655 |
EXTRUSION BUMPER (3 2) (2 2) Price: $5.99 |
| 150 |
532190309 |
DUCT.HEAT.HOOD.STEALTH.GT This part replaces 532161237. Price: $39.99 |
| 152 |
532177956 |
BROWNING SHIELD Price: $29.99 |
| 153 |
532179765 |
LIGHT ASM. Price: $61.09 |
| 158 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 161 |
532181787 |
CONSOL.FUEL.WINDOW.BLACK Price: $29.99 |
