| Ref | Part Number | Description |
|---|
| 1 |
03729851 |
SPINDLE,CUTTER HEAD Price: $101.95 |
| 1 |
85-6300 |
Assembly-Plunger Price: Call Us |
| 2 |
03730451 |
LEVER,TILT Price: $27.45 |
| 2 |
85-6290 |
Boot-Rubber Price: Call Us |
| 3 |
03730559 |
MOUNT,CUTTER HEAD PIVOT Price: $81.95 |
| 3 |
85-6280 |
Spring-Return Price: Call Us |
| 4 |
58600300 |
KIT-GUARD Price: Call Us |
| 5 |
03779559 |
GUARD,BLADE Price: $44.95 |
| 6 |
03779667 |
PULLEY, ENGINE This part replaces 03779651. Price: $152.95 |
| 7 |
03779751 |
PULLEY, BLADE Price: Call Us |
| 8 |
58600400 |
KIT-ENGINE BELT FINGER Price: Call Us |
| 9 |
03780000 |
COLLAR, SPRG Price: $24.95 |
| 10 |
03780100 |
FLAP, RUBBER Price: $3.10 |
| 11 |
03789800 |
BLADE, EDGER-9" Price: $15.95 |
| 12 |
03790000 |
SLINGER, BEARING Price: $8.45 |
| 13 |
05408000 |
BRG-BALL .500X1.38X.437 Price: $5.95 |
| 14 |
05500140 |
BSHG-SLV .766 X 1.125 X .500 Price: $3.45 |
| 15 |
05500910 |
BSHG,FLG .384X.635X.41X1.49 Price: $3.45 |
| 16 |
05500912 |
BSHG,FLG .263X.393X.18X.625 Price: $3.45 |
| 17 |
05516400 |
BSHG-SLV .500X.750X1.560 Price: $5.45 |
| 18 |
05902014 |
BLT, HEX .31-24X.750 G5 ZCC This part replaces 05947300. Price: $1.45 |
| 19 |
05901724 |
BLT, HEX .38-16X1.25 G5 ZCC This part replaces 05958000. Price: $1.45 |
| 21 |
05901932 |
BLT, HEX .50-13X4.50 G5 ZCC This part replaces 05962300. Price: $5.95 |
| 22 |
06200307 |
BLT, RHSN .25-20X.750 G5 ZCC This part replaces 06219900. Price: $0.95 |
| 23 |
06300123 |
WSHR, LK-HVY .312X.097 ZCC This part replaces 06307400. Price: $0.45 |
| 24 |
06400901 |
WASHER, BELLEVILLE Price: $3.95 |
| 25 |
06401114 |
WSHR, FLT .520X.827X.062 ZCC This part replaces 06441100. Price: $2.45 |
| 26 |
06401118 |
WSHR, FLT .656X1.313X.095 ZCC This part replaces 06442800. Price: $2.45 |
| 27 |
06445000 |
WSHR-FL-STL .515X1.625X.250 YZ Price: $5.45 |
| 28 |
06401104 |
WSHR, FLT .340X1.125X.135 ZCC This part replaces 06446300. Price: $3.95 |
| 29 |
06500822 |
NUT-LK-TOP-FLG .38-16 ZC120 This part replaces 06542000. Price: $0.95 |
| 30 |
06500903 |
NUT-LK-TOP-FLG .250-20 GF ZCC This part replaces 06543500. Price: $0.95 |
| 31 |
06500907 |
NUT-LK-TOP-FLG .500-13 GF ZCC This part replaces 06543600. Price: $1.45 |
| 32 |
06606100 |
KEY-SQ .188X.75X.188 Price: $3.45 |
| 33 |
06714500 |
PIN, SPRING CLIP Price: $2.45 |
| 34 |
07200507 |
V-BELT, 4L-WRAPPED Price: $28.95 |
| 35 |
07400122 |
SCR-TAP .25-20X.50 HWH ZCC This part replaces 07400034. Price: $0.45 |
| 36 |
08300439 |
SPRING, TORSION Price: $7.95 |
