| Ref | Part Number | Description |
|---|
| 1 |
138024 |
SUB= 145338 Price: Call Us |
| 1 |
98-2354-03 |
LATCH-SEAT Price: $41.34 |
| 2 |
72140506 |
BOLT Price: Call Us |
| 2 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 3 |
138017 |
BRKT ASM SWAY BAR Price: Call Us |
| 3 |
32128-25 |
NUT-HF Price: $3.19 |
| 4 |
138440 |
BRKT DECK SW BAR Price: Call Us |
| 4 |
98-9342 |
DECAL-SOLENOID, INFORMATION Price: $69.36 |
| 4A |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 5 |
98-9302 |
PLATE-STOP, IDLER Price: $12.42 |
| 6 |
130832 |
SUB= 130833 Price: Call Us |
| 6 |
66-4190-03 |
SPRING-IDLER, CLUTCH Price: $7.20 |
| 7 |
105-4674 |
DECAL-NOISE Price: $4.80 |
| 7 |
73800500 |
NUT Price: Call Us |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 8 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 10 |
25-8640 |
SCREW-HH Price: $1.09 |
| 11 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 12 |
98-9311 |
SWIVEL-THROTTLE Price: $28.41 |
| 13 |
137645 |
SUB= 137646 Price: Call Us |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 14 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 16 |
136929 |
SUB= 140329 Price: Call Us |
| 16 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 17 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350-03. Price: $166.30 |
| 17 |
72110618 |
BOLT CARRIAGE Price: Call Us |
| 18 |
106-9224 |
DECAL-DANGER Price: $4.87 |
| 18 |
72140505 |
BOLT Price: Call Us |
| 19 |
233-42 |
KNOB Price: $12.88 |
| 19 |
73800500 |
NUT Price: Call Us |
| 20 |
136888 |
SUB= 918136888 Price: Call Us |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 21 |
73680500 |
SUB= 73690500 Price: Call Us |
| 21 |
98-9303 |
CABLE-THROTTLE Price: $21.41 |
| 22 |
134753 |
STIFFENER BRKT Price: Call Us |
| 22 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 23 |
131267 |
DEFLECTOR BRKT Price: Call Us |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 24 |
98-2352-03 |
FRAME-SEAT Price: $456.00 |
| 25 |
123713X |
SPRING TORSION Price: Call Us |
| 25 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 26 |
110452X |
NUT PUSH M Price: Call Us |
| 26 |
93-0021 |
SWIVEL-CABLE, THROTTLE Price: $33.15 |
| 27 |
130968 |
DEFLECTOR.SHIELD Price: Call Us |
| 27 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
131491 |
HINGE ROD Price: Call Us |
| 29 |
321-4 |
SCREW-HH Price: $0.99 |
| 30 |
138776 |
SUB= 157722 Price: Call Us |
| 30 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 31 |
137266 |
SUB= 139729 Price: Call Us |
| 31 |
75-3680-03 |
ROD-SEAT Price: $38.90 |
| 32 |
129861 |
SUB= 153535 Price: Call Us |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 34 |
72110614 |
BOLT Price: Call Us |
| 35 |
133835 |
XMAS TREE FASTNER Price: Call Us |
| 36 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 37 |
19131612 |
WASHER GT Price: Call Us |
| 38 |
133502 |
RETAINER SPACER Price: Call Us |
| 39 |
133503 |
IDLER ARM STIFF Price: Call Us |
| 40 |
73680600 |
SUB= 73690600 Price: Call Us |
| 41 |
133551 |
PIVOT ROD Price: Call Us |
| 42 |
76020312 |
SUB= 3145 Price: Call Us |
| 43 |
133504 |
CLUTCH ROD SECOND Price: Call Us |
| 44 |
140088 |
GUARD MAND LH BLK Price: Call Us |
| 45 |
4497H |
RETAINER M Price: Call Us |
| 46 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 47 |
131335 |
SPRING EXTENSION Price: Call Us |
| 48 |
133944 |
HARD SMALL WASHER Price: Call Us |
| 49 |
133940 |
SUB= 151785 Price: Call Us |
| 50 |
131340 |
SHOULDER BOLT Price: Call Us |
| 51 |
69180 |
LOCKNUT Price: Call Us |
| 52 |
139888 |
BOLT.SHLD.5/16-18 Price: Call Us |
| 53 |
131845 |
BRAKE PAD ARM ASM Price: Call Us |
| 54 |
133943 |
HARDENED WASHER Price: Call Us |
| 55 |
133844 |
IDLER ARM Price: Call Us |
| 56 |
122052X |
SPACER RETAINER Price: Call Us |
| 57 |
127498 |
BUSHING Price: Call Us |
| 58 |
128759 |
SUB= 918128759 Price: Call Us |
| 59 |
133573 |
CLUTCH ARM PRI AS Price: Call Us |
| 60 |
133550 |
SUB= 142427 Price: Call Us |
| 61 |
131870 |
RETURN SPRING Price: Call Us |
| 62 |
127847 |
CLUTCH ARM SECOND Price: Call Us |
| 63 |
121748X |
WASHER Price: Call Us |
| 64 |
12000029 |
RING Price: Call Us |
| 65 |
128903 |
SHOULDER BOLT Price: Call Us |
| 66 |
127845 |
SPRING KEEPER Price: Call Us |
| 67 |
106932X |
KNOB T(3/8 HOLE) Price: Call Us |
| 68 |
130969 |
BELT-V.92.4.MWR Price: Call Us |
| 69 |
73350600 |
NUT Price: Call Us |
| 70 |
133205 |
TRUNION Price: Call Us |
| 75 |
71161010 |
SCREW Price: Call Us |
| 76 |
19061216 |
WASHER #10 Price: Call Us |
| 77 |
10071000 |
LOCKWASHER Price: Call Us |
| 78 |
130758 |
SUB= 160793 Price: Call Us |
| 79 |
2029J |
WELDNUT Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
