| Ref | Part Number | Description |
|---|
| 1 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532190120. Price: $149.99 |
| 2 |
112-9916 |
HYD CYLINDER ASM Price: $752.66 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
100-4939-03 |
CARRIER-SIDEWINDER Price: $1,133.42 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
99-3575 |
HOSE-HYD Price: $88.37 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
104-0405 |
HOSE-HYD Price: $144.63 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
108-9013 |
HOSE ASM Price: $108.53 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
104-0406 |
HOSE-HYD Price: $148.06 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $17.99 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 11 |
95-8904-0P |
BRACKET This part replaces 95-8904-03. Price: $46.51 |
| 12 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
95-8538 |
SLIDE-PLASTIC Price: $14.81 |
| 14 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 15 |
95-8531 |
SHAFT-PIVOT, LIFTARM Price: $139.66 |
| 16 |
325-10 |
SCREW-HH Price: $1.82 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 19 |
325-19 |
SCREW-HH Price: $2.57 |
| 20 |
95-8884 |
CLAMP Price: $17.91 |
| 21 |
3218-5 |
NUT-JAM Price: $0.27 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
325-7 |
SCREW-HH Price: $1.53 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 24 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 25 |
99-3373 |
BAR-SUPPORT, SLIDE Price: $9.76 |
| 26 |
95-8575 |
PIN-CLEVIS Price: $15.31 |
| 27 |
75-9590 |
SPACER-CYLINDER Price: $6.55 |
| 28 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 29 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 30 |
99-3640 |
TUBE ASM Price: $127.70 |
| 31 |
340-78 |
NUT-LOCK Price: $1.63 |
| 32 |
104-4820-03 |
BRACKET-STOP, CARRIER Price: $200.26 |
| 37 |
136-3423 |
RH LIFTARM ASM This part replaces 115-3466. Price: $260.70 |
| 38 |
136-3421 |
LH LIFTARM ASM This part replaces 115-3465. Price: $260.70 |
| 39 |
323-6 |
SCREW-HH Price: $0.66 |
| 40 |
105-7560 |
SHAFT-CU PIVOT Price: $73.74 |
| 41 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 42 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 43 |
104-0472 |
ROD Price: $44.63 |
| 48 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 49 |
110-8793-03 |
STOP-DECK, RH Price: $37.69 |
| 50 |
110-8794-03 |
STOP-DECK, LH Price: $37.69 |
| 51 |
3269-11 |
RIVET-POP Price: $0.68 |
| 52 |
86-5350 |
BUMPER-RUBBER Price: $46.29 |
| 53 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 54 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 56 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 57 |
110-8787 |
FRONT CARRIER FRAME ASM Price: $525.65 |
| 63 |
104-4828-03 |
BRACKET-ACTUATOR Price: $21.55 |
| 64 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 65 |
32128-44 |
NUT Price: $2.69 |
| 66 |
104-4826-03 |
ACTUATOR-RH Price: $30.11 |
| 67 |
104-4827-03 |
ACTUATOR-LH Price: $28.51 |
| 68 |
104-4819-03 |
BRACKET-PIVOT, LH Price: $37.66 |
| 69 |
104-4825-03 |
BRACKET-PIVOT, RH Price: $37.66 |
| 70 |
323-11 |
SCREW-HH Price: $1.08 |
| 71 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 72 |
104-4821 |
SPRING-TORSION Price: $6.26 |
