| Ref | Part Number | Description |
|---|
| 1 |
100-1535 |
SWITCH Price: $84.91 |
| 1 |
583810001 |
DECK.SVC.48.CC.ASM.668 Price: $699.99 |
| 2 |
539131898 |
MANDREL ASM, CAST IRON Price: $69.99 |
| 2 |
99-7420 |
PLUG-HOLE Price: $7.64 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 4 |
532173434 |
MANDREL PULLEY Price: $14.99 |
| 5 |
596134801 |
Nuts Price: $1.00 |
| 7 |
593649701 |
GSPW Deflectors Price: $84.99 |
| 8 |
587354701 |
SPRING.42.FCS.DEFLECTOR Price: $5.99 |
| 10 |
588811002 |
BLADE.BAGGER.RES.CLRCT.48".BLK Price: $29.99 |
| 11 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 15 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 16 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 17 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 18 |
529470302 |
IDLER ARM This part replaces 588812202. Price: $6.99 |
| 19 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 22 |
589527301 |
WHEEL.GAUGE.RALLY Price: $8.99 |
| 23 |
596434404 |
Bolts Price: $4.99 |
| 24 |
521996502 |
GSPW Nuts Price: $2.99 |
| 26 |
588438301 |
SCREW.7/16-14 X 2.125.WASHER Price: $5.99 |
| 31 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 34 |
532178515 |
WASHER Price: $5.99 |
| 36 |
536050602 |
LINK FIXED MOWER DRAWBAR BLACK This part replaces 587140502. Price: $5.99 |
| 40 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 41 |
594092501 |
Rods Price: $5.99 |
| 42 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 50 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 53 |
599275701 |
Belts This part replaces 588814301. Price: $54.99 |
| 54 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 55 |
596240801 |
GSPW Bolts Price: $3.99 |
| 56 |
596039201 |
GSPW Hardware Price: $2.99 |
| 57 |
587358401 |
SPRING.EXTN.42.FCS.TR.DECK.DRV Price: $6.99 |
| 58 |
532110485 |
BEARING Price: $11.99 |
| 61 |
596274401 |
Rods Price: $9.99 |
| 62 |
596133201 |
Washers Price: $5.99 |
| 63 |
596637301 |
Screws This part replaces 817490410. Price: $2.99 |
| 64 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 67 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 68 |
599972501 |
BOLT This part replaces 596564003. Price: $2.99 |
| 69 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 70 |
595297001 |
Rods Price: $4.99 |
| 71 |
532110452 |
NUT PUSH M Price: $2.99 |
| 73 |
588812402 |
COVER.PNT.MANDREL.RH.GREY Price: $34.99 |
| 74 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 75 |
588813102 |
COVER.PNT.MANDREL.LH.TR.GREY Price: $17.99 |
| 76 |
582541103 |
BUMPER 48 CLEARCUT TRIM SIDE A Price: $11.99 |
| 77 |
582360501 |
BUSHING.NOSE.ROLLER Price: $3.99 |
| 79 |
596136201 |
Bolts Price: $3.99 |
| 80 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 81 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 84 |
596952201 |
Plugs Price: $2.99 |
| 583810001 |
DECK.SVC.48.CC.ASM.668 |
This part replaces 589428801. Price: $699.99 583810001 |
