| Ref | Part Number | Description |
|---|
| 1 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT Price: $69.99 |
| 2 |
98-0902-03 |
PANEL-REAR, RH This part replaces 85-9050. Price: $90.67 |
| 3 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 3 |
594018001 |
Levers This part replaces 532195231. Price: $17.99 |
| 4 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 5 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 6 |
85-8820 |
DISCONTINUED Price: Call Us |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK Price: $7.99 |
| 7 |
94-6045 |
R/H FENDER *R This part replaces 85-9530. Price: $406.33 |
| 8 |
3230-18 |
SCREW-CARR Price: $4.09 |
| 9 |
322-2 |
SCREW-HH Price: $0.69 |
| 10 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 11 |
85-8840 |
DECAL-WARNING Price: $36.12 |
| 12 |
85-9500 |
DISCONTINUED Price: Call Us |
| 13 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 14 |
46-6890 |
DISCONTINUED Price: Call Us |
| 15 |
322-1 |
SCREW-HH Price: $0.22 |
| 16 |
94-6044 |
LH FENDER ASM This part replaces 14-7509. Price: $363.17 |
| 17 |
32128-20 |
NUT-HF Price: $0.99 |
| 18 |
321-3 |
SCREW-HH Price: $0.28 |
| 19 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 20 |
3219-14 |
NUT-HEX Price: $0.25 |
| 21 |
3218-13 |
NUT-JAM, BRASS Price: $0.88 |
| 22 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 23 |
28-4210 |
SOLENOID Price: $63.91 |
| 24 |
98-0903-03 |
PANEL-REAR, LH This part replaces 85-9040. Price: $97.72 |
| 25 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 26 |
3296-8 |
NUT-HEX Price: $1.29 |
| 27 |
85-9680-01 |
PANEL-LH This part replaces 85-9680. Price: $444.11 |
| 28 |
85-7600 |
DISCONTINUED Price: Call Us |
| 29 |
85-8490 |
DISCONTINUED Price: Call Us |
| 30 |
88-8130 |
DISCONTINUED Price: Call Us |
| 31 |
85-9310 |
CONTROL-CHOKE / THROTTLE Price: $70.61 |
| 32 |
80-2150 |
PAD-LITTER BOX Price: $9.67 |
| 33 |
85-9190-03 |
CONTROL PLATE This part replaces 85-9190. Price: $9.11 |
| 34 |
85-8800 |
DECAL-SANDPRO 5000 Price: $35.29 |
| 35 |
88-8340 |
DISCONTINUED Price: Call Us |
| 36 |
85-8880 |
DECAL-MISSING, SHIELD Price: $11.65 |
| 37 |
93-9050 |
DECAL-INSTRUCTIONS, OPERATING This part replaces 85-8810. Price: $29.50 |
| 38 |
85-8790 |
TREAD-FLOOR, LH Price: $27.04 |
| 39 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 40 |
32148-8 |
NUT-CLINCH Price: $2.31 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST Price: $9.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464807 |
Links This part replaces 532195181. Price: $14.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 98 |
581506903 |
Links This part replaces 532195270. Price: $9.99 |
| 101 |
532407003 |
LINK.ASM.LIFT.FIXE.38/42/46" Price: $11.99 |
