| Ref | Part Number | Description |
|---|
| 1 |
127-6487 |
DECK ASM This part replaces 108-9903. Price: $3,916.83 |
| 1 |
930-054A |
TRANSAXLE, PEERLESS Price: Call Us |
| 2 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 2 |
146682 |
SPRING.BRAKE.RETU Price: Call Us |
| 3 |
123666X |
PULLEY TRANS Price: Call Us |
| 4 |
12000028 |
SUB= 2267J Price: Call Us |
| 4 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 5 |
121520X |
STRAP TORQUE Price: Call Us |
| 6 |
17490512 |
SCREW Price: Call Us |
| 6 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 7 |
130802 |
SUB= 162240 Price: Call Us |
| 7 |
325-18 |
SCREW-HH Price: $3.19 |
| 8 |
131679 |
SHIFT ROD Price: Call Us |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 10 |
76020416 |
PIN COTTER 1/8 Price: Call Us |
| 11 |
105701X |
WASH-SHFT PLT LT Price: Call Us |
| 11 |
140-5847 |
PULLEY-IDLER This part replaces 01-268-0160. Price: $98.46 |
| 12 |
19151216 |
WASHER Price: Call Us |
| 13 |
68-6710 |
ROLLER Price: $59.98 |
| 13 |
74550412 |
BOLT.1/4-28.W/PAT Price: Call Us |
| 14 |
10040400 |
LOCKWASHER Price: Call Us |
| 14 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 104-3532. Price: $589.65 |
| 15 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 15 |
74490544 |
BOLT.HX.FLG.5/16 Price: Call Us |
| 16 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 17 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 18 |
107-4725 |
PULLEY Price: $274.56 |
| 18 |
74780616 |
BOLT Price: Call Us |
| 19 |
108-1924 |
SPACER-IDLER Price: $11.13 |
| 19 |
73800600 |
NUT Price: Call Us |
| 20 |
140-7079 |
IDLER ARM ASM This part replaces 110-3564. Price: $49.85 |
| 21 |
106933X |
KNOB T (1/2-HOLE) Price: Call Us |
| 21 |
110-9592 |
BELT-V Price: $64.65 |
| 22 |
130804 |
BRAKE ROD Price: Call Us |
| 23 |
132-9421 |
PULLEY-IDLER, FLAT This part replaces 110-9596. Price: $41.10 |
| 24 |
139-1038 |
HIGH DRIVEN SPINDLE ASM This part replaces 104-3531. Price: $691.39 |
| 24 |
73350600 |
NUT Price: Call Us |
| 25 |
106888X |
SPRING ROD LT Price: Call Us |
| 25 |
139-1037 |
DOUBLE DRIVEN SPINDLE ASM This part replaces 104-3530. Price: $724.15 |
| 26 |
108-1926 |
WASHER Price: $5.30 |
| 26 |
19131316 |
WASHER Price: Call Us |
| 27 |
108-1921 |
SPRING-TORSION Price: $28.33 |
| 27 |
76020412 |
COTTER PIN Price: Call Us |
| 28 |
140-7078 |
IDLER ARM ASM This part replaces 108-1930. Price: $49.85 |
| 28 |
145204 |
ROD.BRAKE.PARK.LT Price: Call Us |
| 29 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 29 |
71673 |
PLUNGER CAP T Price: Call Us |
| 30 |
130807 |
TRANSAXLE MTG BKT Price: Call Us |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
110-9593 |
BELT - V Price: $73.36 |
| 32 |
3296-45 |
NUT-HEX Price: $3.79 |
| 32 |
74760512 |
BOLT Price: Call Us |
| 34 |
155071 |
SHAFT ASM-PEDAL F Price: Call Us |
| 34 |
29-4820 |
ROLLER Price: $14.88 |
| 35 |
120183X |
NYLON BEARING Price: Call Us |
| 35 |
325-14 |
SCREW-HH Price: $2.64 |
| 36 |
19211616 |
WASHER LT Price: Call Us |
| 36 |
3218-5 |
NUT-JAM Price: $0.27 |
| 37 |
1572H |
SUB= 2882J Price: Call Us |
| 38 |
123674X |
PULLEY.IDLER.FLAT Price: Call Us |
| 39 |
74760644 |
BOLT Price: Call Us |
| 40 |
4470J |
SPACER T Price: Call Us |
| 41 |
154777 |
SUB= 165692 Price: Call Us |
| 42 |
19131312 |
WASHER Price: Call Us |
| 46 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 47 |
127783 |
SUB= 139245 Price: Call Us |
| 48 |
154604 |
BELLCRANK ASM Price: Call Us |
| 49 |
123205X |
RETAIN BELT Price: Call Us |
| 50 |
74760624 |
SUB= 74930624 Price: Call Us |
| 51 |
73680600 |
SUB= 73690600 Price: Call Us |
| 52 |
73680500 |
SUB= 73690500 Price: Call Us |
| 54 |
2751R |
CLIP T Price: Call Us |
| 56 |
74760620 |
Bolt Fin Flex 3/8-16unc X 1-1/4 Price: Call Us |
| 57 |
130801 |
SUB= 138255 Price: Call Us |
| 59 |
140312 |
KEEPER BELT CNTSP Price: Call Us |
| 61 |
17490612 |
SCREW Price: Call Us |
| 62 |
8883R |
PEDAL COVER T Price: Call Us |
| 63 |
140186 |
PULLEY.ENGINE Price: Call Us |
| 64 |
71170764 |
BOLT Price: Call Us |
| 65 |
10040700 |
LOCKWASHER Price: Call Us |
| 66 |
154778 |
KEEPER-BELT Price: Call Us |
| 70 |
134683 |
KEEPER BELT ENG Price: Call Us |
| 72 |
19132012 |
WASHER Price: Call Us |
| 74 |
137057 |
SPACER AXLE Price: Call Us |
| 75 |
121749X |
WASHER Price: Call Us |
| 76 |
12000001 |
E-RING LT Price: Call Us |
| 77 |
123583X |
SQUARE KEY Price: Call Us |
| 78 |
121748X |
WASHER Price: Call Us |
| 79 |
2228M |
SUB= 2228M1 Price: Call Us |
| 96 |
4497H |
RETAINER M Price: Call Us |
| 112 |
19091210 |
WASHER LT Price: Call Us |
| 116 |
72110610 |
BOLT RDHD 3/8-16 Price: Call Us |
| 118 |
154774 |
SPACER-BELLCRANK Price: Call Us |
