| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 1 |
98-5352 |
COVER ASM Price: $509.16 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
98-5353 |
NEEDLE BEARING Price: Call Us |
| 3 |
98-5354 |
NEEDLE BEARING Price: Call Us |
| 4 |
98-5355 |
CASE ASM Price: $1,236.97 |
| 5 |
98-5356 |
OUTPUT SHAFT Price: $245.23 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
98-5357 |
OUTPUT GEAR Price: $158.45 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
98-5358 |
BEVEL GEAR Price: Call Us |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
98-5359 |
BEVEL PINION Price: $94.34 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
98-5360 |
RING GEAR Price: $347.60 |
| 10 |
95-7213 |
BLOCK - DRIVE Price: $19.96 |
| 11 |
95-7212 |
PIN - DRIVE Price: $19.00 |
| 12 |
98-5361 |
SCREW - 1/4-20 X 1.00 Price: Call Us |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
98-5362 |
SCREW - 3/8-16 X 2.00 Price: Call Us |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
98-5363 |
RETAINING RING Price: Call Us |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 15 |
95-5745 |
WASHER This part replaces 95-7244. Price: $2.17 |
| 16 |
252-80 |
WASHER-THRUST Price: $7.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 17 |
95-7257 |
WASHER Price: $9.24 |
| 18 |
98-5364 |
BRAKE DISK Price: Call Us |
| 19 |
98-5365 |
BRAKE PAD PLATE Price: Call Us |
| 20 |
98-5366 |
BRAKE PAD (PKG 2) Price: Call Us |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 21 |
95-7236 |
PIN - DOWEL Price: $3.56 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 22 |
98-5367 |
FLAT WASHER .312 10 Price: $4.20 |
| 23 |
98-5368 |
BRAKE LEVER Price: $45.82 |
| 24 |
98-5369 |
SCREW - 1/4-20 X 1.25 Price: Call Us |
| 25 |
98-5370 |
SCREW - 1/4-20 X 2.25 Price: Call Us |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
98-5371 |
LOCKNUT 5/16-24 Price: Call Us |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 27 |
98-5372 |
BRAKE PAD HOLDER Price: $41.03 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 28 |
98-5373 |
SPACER Price: Call Us |
| 29 |
98-5374 |
BRAKE LEVER BRACKET Price: Call Us |
| 30 |
98-5375 |
AXLE Price: $296.40 |
| 31 |
98-5376 |
AXLE Price: Call Us |
| 32 |
98-5377 |
SHIFTER BRAKE SHAFT Price: $282.79 |
| 33 |
98-5378 |
NEEDLE BEARING Price: $56.46 |
| 34 |
98-5379 |
FLAT WASHER Price: Call Us |
| 35 |
281-2 |
PLUG-PIPE, SQH Price: $2.09 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
76-6030 |
SEAL-OIL This part replaces 27-6420. Price: $17.61 |
| 37 |
98-5380 |
OIL SEAL Price: $51.03 |
| 38 |
98-5381 |
DIFFERENTIAL CARRIER Price: Call Us |
| 39 |
98-5382 |
DIFFERENTIAL CARRIER Price: $195.69 |
| 40 |
98-5383 |
SCREW - 1/4-20 X 2.25 Price: Call Us |
| 41 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 42 |
98-5384 |
CASE-TO-COVER GASKET Price: Call Us |
| 43 |
98-5385 |
IDLER GEAR Price: $111.19 |
| 44 |
98-5386 |
AXLE HOUSING ASM Price: Call Us |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 45 |
98-5387 |
BUSHING Price: $67.91 |
| 46 |
98-5388 |
ADAPTER PLATE Price: $561.45 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
