| Ref | Part Number | Description |
|---|
| 1 |
3269-25 |
RIVET-POP Price: $0.27 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 2 |
531171101 |
SERVICE KIT AXLE HALF ASM This part replaces 532154427. Price: $59.99 |
| 3 |
40-9520 |
SPACER Price: $0.33 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
40-0330 |
CUSHION-RUBBER Price: $8.08 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
32122-28 |
SCREW Price: $5.02 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
323-6 |
SCREW-HH Price: $0.66 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
69-6730-01 |
SKID ASM Price: $264.77 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
32128-23 |
NUT-HF Price: $1.51 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
3233-9 |
SCREW-CARR Price: $1.97 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
32128-21 |
NUT-HF Price: $0.39 |
| 10 |
532169832 |
DRAGLINK.15".TIRES Price: $64.99 |
| 11 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
106-0039 |
LH WING DECK ASM This part replaces 13-4989. Price: $1,850.37 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 13 |
69-6640-01 |
HINGE-FRONT, LEFT Price: $157.33 |
| 14 |
69-6900 |
SHAFT-HINGE Price: $62.29 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 15 |
69-6260 |
MAGNET Price: $58.32 |
| 16 |
95-3297 |
BEARING-THRUST Price: $4.11 |
| 17 |
531166901 |
SERVICE KIT SHAFT ASM ST This part replaces 532156546. Price: $42.99 |
| 17 |
69-6670-01 |
HINGE-REAR, LEFT Price: $162.98 |
| 18 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT Price: $8.99 |
| 19 |
94-6760-01 |
BRACKET-LH Price: $94.57 |
| 20 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 21 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 22 |
532165857 |
SCREW.HX.WSH.HD Price: $3.99 |
| 22 |
69-6850 |
DISCONTINUED Price: Call Us |
| 23 |
531154301 |
SERVICE.KIT SHAFT ASSY SHAFT A This part replaces 532165851. Price: $22.99 |
| 23 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 23 |
93-7824 |
DECAL-DANGER Price: $17.85 |
| 24 |
106-6753 |
DECAL-DANGER, CE This part replaces 93-7815. Price: $8.07 |
| 24 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 25 |
106-8120 |
DECAL-DANGER, CE This part replaces 93-7273. Price: $9.83 |
| 25 |
532154406 |
BRACKET STEERING Price: $6.99 |
| 25 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 26 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 26 |
532126847 |
BUSHING.DRAGLINK (2 2) Price: $4.99 |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 27 |
82-4910 |
ROLLER Price: $26.42 |
| 28 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 28 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 29 |
88-9270-01 |
BRACKET-ROLLER, LH Price: $110.38 |
| 30 |
5-0838 |
WASHER Price: $1.09 |
| 30 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 31 |
323-7 |
SCREW-HH Price: $0.65 |
| 32 |
532192757 |
ROD.TIE.WIRE.FORM This part replaces 532130465. Price: $29.99 |
| 32 |
94-9824-01 |
BAR-GUARD, FRONT WING LH This part replaces 94-9824. Price: $103.08 |
| 33 |
32144-11 |
SCREW-THD ROLL, HWH This part replaces 32104-31. Price: $6.99 |
| 34 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 35 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
819132411 |
Washer 13/32 X 1-1/20 x 11 Ga Price: $2.99 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532153721 |
SHAFT EXT STEERING This part replaces 532153720. Price: $54.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 51 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 54 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 62 |
584371701 |
KIT.STEER.ASM.P/L This part replaces 532167902. Price: $119.99 |
| 63 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 66 |
532154404 |
BEARING ARM Price: $3.99 |
| 67 |
872110618 |
BOLT CARRIAGE This part replaces 872140618. Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 79 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 80 |
874950612 |
BOLT.HX.NYLON3/8-16X Price: $4.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
