| Ref | Part Number | Description |
|---|
| 1 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 1 |
532406623 |
SEAT.TP150.BLK.PPRO.KB/SL Price: $169.99 |
| 2 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $5.99 |
| 3 |
68-6710 |
ROLLER Price: $59.98 |
| 4 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 5 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 6 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 6 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK Price: $2.99 |
| 8 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 8 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 9 |
3269-24 |
RIVET Price: $1.79 |
| 10 |
532441805 |
PAN.ASM.SEAT.SHORT.SLD.ADJ.TEX Price: $29.99 |
| 10 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 11 |
108-1908 |
SPACER-IDLER Price: $23.93 |
| 12 |
3233-34 |
SCREW-CARR Price: $7.98 |
| 12 |
532199370 |
BRKT.MNT.OPC.SW.SEAT. Price: $2.99 |
| 13 |
107-4788 |
BELT-HEX Price: $178.28 |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 14 |
140-5847 |
PULLEY-IDLER This part replaces 01-268-0160. Price: $98.46 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 15 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
108-1926 |
WASHER Price: $5.30 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 18 |
108-1921 |
SPRING-TORSION Price: $28.33 |
| 19 |
140-7078 |
IDLER ARM ASM This part replaces 108-1930. Price: $49.85 |
| 19 |
532199372 |
KNOB.SEAT.ADJ. Price: $4.99 |
| 21 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER Price: $1.99 |
| 22 |
3296-45 |
NUT-HEX Price: $3.79 |
| 23 |
108-1924 |
SPACER-IDLER Price: $11.13 |
| 24 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 25 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 26 |
111-5429 |
PAD-BUMPER Price: $3.00 |
| 29 |
139-1035 |
SINGLE DRIVING SPINDLE ASM This part replaces 119-4547. Price: $986.94 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 37 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 42 |
532199371 |
WASHER.CUP.SEAT. Price: $2.99 |
