| Ref | Part Number | Description |
|---|
| 1 |
125-7120 |
ALTERNATOR-12V Price: $755.08 |
| 2 |
125-7121 |
BOLT-STOPPER Price: $132.38 |
| 3 |
125-7122 |
PIECE-DISTANCE Price: $15.42 |
| 4 |
125-7230 |
NUT Price: $2.81 |
| 5 |
125-6947 |
SPACER Price: $21.65 |
| 6 |
125-7101 |
ADJUSTER-BELT Price: $132.31 |
| 6 |
532140051 |
BRACKET ASSY HOOD Price: $3.68 |
| 7 |
125-7134 |
BOLT Price: $25.74 |
| 7 |
532140050 |
BRACKET ASSY Price: $3.99 |
| 8 |
125-7219 |
BOLT Price: $4.58 |
| 9 |
125-7173 |
RELAY Price: $36.87 |
| 10 |
125-7131 |
WASHER Price: $3.48 |
| 11 |
532140142 |
HOOD - LR Price: $339.99 |
| 12 |
532157067 |
LENS Price: $19.99 |
| 13 |
532404673 |
GRILLE.KIT.SERVICE.HUSQ.LR This part replaces 532156871. Price: $449.99 |
| 17 |
596582501 |
Bolts This part replaces 874780410. Price: $2.99 |
| 20 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 21 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 22 |
532157066 |
LENS Price: $24.99 |
| 23 |
532139969 |
HOOD LATCH Price: $3.45 |
| 24 |
532142873 |
BRACKET PIVOT Price: $2.99 |
| 26 |
532052921 |
CLIP TINNERMAN Price: $2.68 |
| 28 |
811050400 |
Washer, Lock, External Tooth 1/4 Price: $5.99 |
| 34 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 35 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 36 |
532128445 |
BRACKET HOOD Price: $2.99 |
