| Ref | Part Number | Description |
|---|
| 1 |
340-159 |
FITTING-HYD, 90 DEG This part replaces 98-1281. Price: $55.33 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532141525. Price: $219.99 |
| 2 |
322-3 |
SCREW-HH Price: $0.79 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 4 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 4 |
82-9330 |
BRACKET - SENSOR *R Price: $24.29 |
| 5 |
23-1840 |
BUSHING-TAPERLOCK Price: $92.22 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
237-22 |
O-RING Price: $2.43 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
237-42 |
O-RING Price: $2.78 |
| 8 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 9 |
58-0070 |
DISC BRAKE ASM Price: $316.73 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532140552. Price: $17.99 |
| 10 |
86-5480 |
NIPPLE-TEST Price: $48.77 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 12 |
58-5430 |
PISTON MOTOR ASM Price: $3,072.75 |
| 13 |
237-81 |
O-RING Price: $2.76 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
872050411 |
Bolt, Carriage 1/4-20 X 1-3/8 Price: $3.99 |
| 14 |
92-6058 |
FITTING-STR Price: $105.61 |
| 15 |
237-58 |
O-RING Price: $2.18 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
323-18 |
SCREW-HH Price: $0.82 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
353-949 |
O-RING Price: $3.49 |
| 18 |
819171912 |
WASHER Price: $3.99 |
| 19 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 19 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT This part replaces 532120068. Price: $6.99 |
| 20 |
327-3 |
SCREW-HH Price: $1.49 |
| 20 |
532124238 |
CAP SPRING Price: $4.99 |
| 21 |
532139888 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 21 |
62-6400-03 |
HUB-WHEEL, DRIVE Price: $3,397.53 |
| 22 |
3247-10 |
SETSCREW Price: $0.55 |
| 23 |
3219-5 |
NUT-HEX Price: $1.22 |
| 24 |
58-5610 |
RIM Price: $360.43 |
| 25 |
58-5620 |
TUBE Price: $89.16 |
| 26 |
136-3327 |
TIRE This part replaces 63-4480. Price: $404.86 |
| 27 |
323-20 |
SCREW-HH Price: $1.28 |
| 28 |
58-3780 |
TUBE-SPACE Price: $25.99 |
| 29 |
29-1060 |
BRACKET-SECONDARY Price: $135.49 |
| 30 |
353-947 |
CAP-DUST, RUBBER Price: $7.73 |
| 32 |
58-0110-03 |
BRACKET-CALIPER, BRAKE Price: $142.37 |
| 33 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 34 |
29-1070 |
LEVER ASM Price: $64.17 |
| 35 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 36 |
60-1740 |
NUT Price: $1.53 |
| 37 |
58-2300 |
LINK-BRAKE Price: $30.30 |
| 38 |
283-67 |
PIN-CLEVIS Price: $2.04 |
| 39 |
29-1080 |
BRAKE PAD Price: $66.87 |
| 40 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 41 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 42 |
82-9280 |
DISC WA Price: $599.98 |
| 43 |
98-1282 |
ADAPTER-HYD, STRAIGHT Price: $54.52 |
| 45 |
75-6700 |
SENDER-MAGNETIC Price: $229.36 |
