| Ref | Part Number | Description |
|---|
| 1 |
21-4120 |
Roll Bar Ass-y. Price: Call Us |
| 2 |
36-7910 |
Warning Decal Price: Call Us |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $49.99 |
| 3 |
325-7 |
SCREW-HH Price: $1.53 |
| 4 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 5 |
21-4190 |
DISCONTINUED Price: Call Us |
| 6 |
324-4 |
SCREW-HH Price: $0.95 |
| 7 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 8 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 9 |
32146-13 |
NUT-HEX Price: $3.49 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 Price: $7.99 |
| 10 |
21-4310 |
Rear Mount Price: Call Us |
| 11 |
325-14 |
SCREW-HH Price: $2.64 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $199.99 |
| 12 |
325-9 |
SCREW-HH Price: $1.87 |
| 12 |
532402980 |
PULLEY.ENGINE.ENX Price: $54.99 |
| 13 |
21-4390 |
Front Mount L.H. Price: Call Us |
| 15 |
532433007 |
TANK.ASM.FRT.2.5 GAL.W/CAP.EPA Price: $119.99 |
| 18 |
581176101 |
CAP.FUEL.2 WAY VENT Price: $34.99 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $29.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 28 |
532401137 |
LINE.FUEL.20"FRONT.EMI Price: $9.99 |
| 29 |
532131780 |
Kit Spark Arrestor 1 25 Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $3.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 Price: $9.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $9.99 |
| 79 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 85 |
532179953 |
BOLT HEX 7/16-20 X 3.75 GR. 5 Price: $3.99 |
| 87 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $2.99 |
| 96 |
819091416 |
WASHER Price: $3.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
