| Ref | Part Number | Description |
|---|
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
588826101 |
DECK.SVC 48" W/DECALS X498 This part replaces 574808901. Price: $849.99 |
| 2 |
32128-21 |
NUT-HF Price: $0.39 |
| 2 |
539112170 |
MANDREL.DECK.ASSEMBLY Price: $69.99 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 3 |
92-7472 |
REAR TUBE ASM Price: $185.79 |
| 4 |
532174375 |
PULLEY.DRIVEN.DECK.48' Price: $34.99 |
| 4 |
92-7473 |
REAR TUBE ASM Price: $239.26 |
| 5 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 5 |
76-8350 |
STOP-AXLE Price: $10.92 |
| 6 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 6 |
93-7247 |
WASHER-THRUST Price: $3.46 |
| 7 |
237-58 |
O-RING Price: $2.18 |
| 7 |
539110732 |
DISCHARGE CHUTE 48" Price: $44.99 |
| 8 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 8 |
596646001 |
Springs This part replaces 539110735. Price: $3.99 |
| 9 |
595935501 |
Pins This part replaces 539110736. Price: $2.99 |
| 9 |
92-7536 |
HOSE-HYD Price: $196.76 |
| 10 |
105-9818 |
HOSE-HYD This part replaces 92-7537. Price: $287.57 |
| 10 |
539113425 |
BLADE, 16-1/4" Price: $19.99 |
| 11 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 11 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 12 |
3256-29 |
WASHER-FLAT Price: $2.59 |
| 12 |
539113427 |
CONFINEMENT PLATE 48" BLK This part replaces 539113426. Price: $32.99 |
| 13 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 13 |
94-8000 |
NUT-HEX Price: $2.65 |
| 14 |
32151-96 |
RING-RETAINING Price: $0.54 |
| 14 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 15 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 15 |
71-4580 |
BEARING Price: $80.51 |
| 16 |
71-4590 |
WASHER-THRUST Price: $3.32 |
| 17 |
237-166 |
O-RING Price: $10.46 |
| 17 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 18 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 18 |
574827102 |
ARM, IDLER, BLK This part replaces 574827101. Price: $27.99 |
| 19 |
237-81 |
O-RING Price: $2.76 |
| 19 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 20 |
589766102 |
Pulleys This part replaces 539132728. Price: $27.99 |
| 20 |
92-7386 |
HYD MOTOR ASM Price: $2,754.42 |
| 21 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 21 |
575224501 |
BUSHING, IDLER Price: $27.99 |
| 22 |
325-4 |
SCREW-HH Price: $0.95 |
| 22 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 23 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 23 |
94-3099 |
GEAR - DRIVEN, 10 PITCH Price: $177.13 |
| 24 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 24 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 25 |
94-3098 |
GEAR - DRIVEN, 10 PITCH Price: $199.13 |
| 26 |
340-70 |
NUT-LOCK Price: $2.10 |
| 27 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 27 |
92-7553 |
TUBE-REAR DRAIN Price: $174.40 |
| 28 |
539108271 |
HCS 3/8-16 X 3-1/2 GR5 ZD Price: $4.99 |
| 28 |
92-7495 |
STEERING TUBE ASM Price: $148.27 |
| 29 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 29 |
92-7494 |
REAR STEARING TUBE ASM Price: $150.03 |
| 30 |
596433701 |
GSPW Washers This part replaces 819141614. Price: $2.99 |
| 30 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 31 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 31 |
92-7534 |
HOSE-HYD Price: $123.48 |
| 32 |
539990923 |
RHSNB 3/8-16X1-3/4 Price: $2.99 |
| 32 |
98-7825 |
DISCONTINUED ,ORDER PIECE PARTS This part replaces 93-7780. Price: Call Us |
| 33 |
596437601 |
Washers This part replaces 539104864. Price: $2.99 |
| 33 |
86-5910 |
TIRE-6 PLY Price: $114.98 |
| 34 |
120-8909 |
RIM This part replaces 217-125. Price: $198.53 |
| 34 |
532178515 |
WASHER Price: $5.99 |
| 35 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 35 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 36 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 36 |
74-5500 |
BOLT-WHEEL Price: $10.84 |
| 37 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 37 |
596241101 |
Bolts This part replaces 539113621. Price: $2.99 |
| 38 |
237-42 |
O-RING Price: $2.78 |
| 38 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 39 |
353-508 |
PLUG-HH Price: $7.96 |
| 39 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 40 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 40 |
92-7539 |
HOSE-HYD Price: $134.23 |
| 41 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 41 |
92-7538 |
HOSE ASM Price: $167.59 |
| 42 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 43 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 43 |
94-9973 |
RING-RETAINING Price: $1.02 |
| 44 |
121-3653 |
CYLINDER-HYD This part replaces 94-8141. Price: $725.74 |
| 44 |
575967201 |
Price: Call Us |
| 45 |
596580801 |
Bolts This part replaces 874780516. Price: $2.99 |
| 45 |
92-5839 |
JOINT-BALL Price: $207.89 |
| 46 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810030500. Price: $2.99 |
| 46 |
92-5833 |
SPACER-JOINT, BALL Price: $20.71 |
| 47 |
92-5844 |
DISCONTINUED Price: Call Us |
| 48 |
32136-14 |
NUT-HST Price: $3.38 |
| 49 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 50 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 50 |
92-5836 |
WASHER Price: $5.34 |
| 51 |
237-78 |
O-RING Price: $3.85 |
| 51 |
596437001 |
Screws This part replaces 817490408. Price: $2.99 |
| 52 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 52 |
596435201 |
Bolts This part replaces 874780740. Price: $2.99 |
| 53 |
574845602 |
BELT, 135" EL Price: $79.99 |
| 53 |
92-7604 |
DISCONTINUED Price: Call Us |
| 54 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 54 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 55 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 55 |
94-8115 |
DISCONTINUED Price: Call Us |
| 56 |
325-33 |
SCREW-HH Price: $11.49 |
| 57 |
596645601 |
Springs This part replaces 539106850. Price: $8.99 |
| 57 |
92-7646 |
ELBOW-BULKHEAD, 45 DEG Price: $105.61 |
| 58 |
532110485 |
BEARING Price: $11.99 |
| 58 |
69-8910 |
WASHER Price: $1.70 |
| 59 |
575352901 |
RP PULLEY, COLLECTION 48 Price: $54.99 |
| 59 |
69-8900 |
SPACER Price: $14.26 |
| 60 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 60 |
92-7552-03 |
DISCONTINUED This part replaces 92-7552. Price: Call Us |
| 61 |
240-7 |
GROMMET-RUBBER Price: $16.51 |
| 61 |
532404851 |
ROD.ANTI.SWAY.48/54"K4 Price: $22.99 |
| 62 |
106-6774 |
JOINT-BALL This part replaces 92-5838. Price: $79.04 |
| 62 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 63 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 63 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 64 |
237-22 |
O-RING Price: $2.43 |
| 65 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 66 |
88-1550 |
STOP - 4WD AXLE Price: $47.56 |
| 67 |
94-2806 |
ADAPTOR-STUD, WHEEL Price: $57.68 |
| 68 |
100-3895-03 |
WEIGHT-WHEEL This part replaces 94-3052. Price: $841.13 |
| 69 |
3213-14 |
SCREW-HH Price: $8.01 |
