| Ref | Part Number | Description |
|---|
| 1 |
63-7700 |
DISCONTINUED Price: Call Us |
| 1 |
925-0023B |
TAIL LIGHT ASSEMBLY-RIGHT Not Available This part replaces 625-0023B. Price: |
| 2 |
63-7710 |
STRIP-MAGNETIC Price: $11.89 |
| 2 |
925-0024B |
TAIL LIGHT ASSEMBLY-LEFT This part replaces 625-0024B. Price: $120.24 |
| 3 |
32128-20 |
NUT-HF Price: $0.99 |
| 3 |
703-3451 |
SEAT MOUNTING BRACKET (LH) Not Available Price: |
| 4 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 4 |
703-3572 |
BRACKET (RH) SEAT MTG Not Available Price: |
| 5 |
703-3754 |
REAR BRACKET SEAT MTG Not Available Price: |
| 5 |
92-5757-03 |
SUPPORT-RADIATOR ASM This part replaces 92-5757. Price: $284.64 |
| 6 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 6 |
710-0604A |
Screw, Hex Wash Hd. Tapp 5/16-18 x .625 Price: $3.96 |
| 7 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 7 |
710-3038 |
Screw, Hex Cap 5/16-18 x .875 GR5 Price: $4.17 |
| 8 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 8 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 9 |
110-4112 |
HOSE-FUEL This part replaces 71-3384. Price: $12.60 |
| 9 |
710-3021 |
SCREW 5/16-18 x .625 Not Available Price: |
| 10 |
66-8180 |
HYDRAULIC HOSE ASM Price: $119.78 |
| 10 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 11 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 11 |
710-1242 |
Screw, Truss Phillips Hd 5/16-14 x .75 Price: $3.95 |
| 12 |
710-1260A |
Screw, Hex Wash Hd. Tapp 5/16-18 x .75 Price: $3.34 |
| 12 |
76-8750 |
PLATE-WARNING Price: $9.67 |
| 12 |
93-6681 |
DECAL-WARNING, FAN Price: $11.51 |
| 13 |
3290-271 |
RIVET-POP Price: $0.25 |
| 13 |
710-0971 |
SCREW 5/16-18 x 1 Not Available Price: |
| 14 |
726-3057 |
TAIL LIGHT CLIP Not Available Price: |
| 15 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 15 |
726-3046 |
Clip, Ratchet Fastener Price: $3.71 |
| 16 |
321-4 |
SCREW-HH Price: $0.99 |
| 16 |
726-0211 |
Speed Nut, "U" Type, 5/16-18 Price: $3.90 |
| 17 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 17 |
731-3324A |
FOOTBOARD COVER Not Available This part replaces 731-3324. Price: |
| 18 |
731-3289 |
FENDER-FOOTBOARD & Not Available Price: |
| 18 |
93-9940 |
DISCONTINUED Price: Call Us |
| 19 |
731-04005 |
Cover, Fender, RH Price: Call Us |
| 19 |
84-7680 |
FAN SHROUD This part replaces 92-6503. Price: $256.05 |
| 20 |
66-3180 |
TUBE-VENT Price: $18.60 |
| 20 |
731-04006 |
Cover, Fender, LH Price: Call Us |
| 21 |
63-6020 |
HOSE - LOWER RADIATOR Price: $78.30 |
| 21 |
735-0669 |
FOOTBOARD PAD (RH) Not Available Price: |
| 22 |
2412-103 |
CLAMP Price: $2.51 |
| 22 |
735-0670 |
FOOTBOARD PAD (LH) Not Available Price: |
| 23 |
735-0690 |
Grommet, .4375 ID x .75 Price: $10.52 |
| 24 |
736-3089 |
FLAT WASHER .345X1.0X.100 Not Available Price: |
| 25 |
736-0173 |
Washer, Flat, .28 x .74 x .063 Price: $3.76 |
| 26 |
119-2241 |
COOLING ASM This part replaces 82-2310. Price: $1,497.64 |
| 27 |
63-6440-03 |
SHIELD-RADIATOR, BOTTOM This part replaces 63-6440. Price: $115.58 |
| 28 |
304-46 |
DRAINCOCK Price: $7.55 |
| 29 |
3269-10 |
WASHER-BACK Price: $0.61 |
| 30 |
66-8500 |
HYD HOSE ASM Price: $89.96 |
| 31 |
3269-13 |
RIVET-POP Price: $0.25 |
| 35 |
110-7501 |
HOSE-FUEL This part replaces 94-4522. Price: $12.75 |
| 36 |
3249-3 |
SCREW-PRH Price: $0.34 |
| 37 |
3217-29 |
NUT-HEX Price: $0.25 |
| 777D06180 |
LABEL-FNDR |
POSITRAK Not Available Price: 777D06180 |
| 777S30630 |
LABEL-FOOTBOARD |
WA Not Available Price: 777S30630 |
| 777S30635 |
LABEL-ROPS |
Not Available Price: 777S30635 |
