| Ref | Part Number | Description |
|---|
| 1 |
108-1437 |
ROD END ASM This part replaces 105-7843. Price: $225.70 |
| 2 |
3220-11 |
NUT-JAM Price: $0.81 |
| 2 |
532149723 |
Muffler Side Price: $45.99 |
| 3 |
340-70 |
NUT-LOCK Price: $2.10 |
| 4 |
98-3867 |
WASHER-THRUST Price: $3.21 |
| 5 |
92-7595 |
HOSE-HYD Price: $102.70 |
| 6 |
92-7594 |
HOSE ASM Price: $94.90 |
| 7 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 8 |
532139123 |
Pulley, V-Idler This part replaces 532121361. Price: $22.99 |
| 8 |
92-1765 |
WASHER-THRUST Price: $2.57 |
| 9 |
100-3770 |
PIN-AXLE, PIVOT Price: $146.29 |
| 9 |
532177748 |
Keeper Asm. Belt Engine VGT Price: $11.99 |
| 10 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 10 |
532175287 |
Bushing Price: $14.99 |
| 11 |
100-3771 |
PIN-STOP Price: $47.62 |
| 11 |
532414737 |
KIT.SVC.CLTCH.OG.1.125" This part replaces 532179335. Price: $225.99 |
| 12 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 12 |
532143996 |
Pulley Engine VGT Elect Clutch Price: $32.99 |
| 13 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 14 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 15 |
532179115 |
Tank Fuel Rear 5.0 Price: $86.99 |
| 15 |
62-2170 |
WASHER-THRUST Price: $4.48 |
| 16 |
100-3785-03 |
REAR AXLE ASM Price: $1,814.62 |
| 17 |
32136-14 |
NUT-HST Price: $3.38 |
| 18 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 18 |
532182902 |
CAP.ASM.FUEL.BLACK This part replaces 532181803. Price: $21.99 |
| 19 |
92-5833 |
SPACER-JOINT, BALL Price: $20.71 |
| 20 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 20 |
532175437 |
CONTROL THROTTLE This part replaces 532178385. Price: $25.99 |
| 21 |
532416358 |
SCREW, NO. 10 This part replaces 532191611. Price: $2.99 |
| 21 |
94-8142 |
HYD CYLINDER ASM Price: $802.19 |
| 22 |
532191596 |
Control Choke Price: $23.99 |
| 22 |
92-5839 |
JOINT-BALL Price: $207.89 |
| 23 |
94-9973 |
RING-RETAINING Price: $1.02 |
| 26 |
532003645 |
Bushing This part replaces 532124952. Price: $2.99 |
| 27 |
532139277 |
Stem Tank Fuel Price: $5.99 |
| 28 |
532008542 |
Line, Fuel This part replaces 532124703. Price: $4.99 |
| 29 |
532137180 |
Spark Arrester Kit Price: $128.99 |
| 31 |
532145006 |
Clip Push-In Hinged Price: $2.99 |
| 37 |
532123487 |
Clamp Hose Price: $3.99 |
| 39 |
817490636 |
Screw TT 3/8-16 x 2-1/4 unc Price: $3.99 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 unc Price: $3.99 |
| 41 |
532126197 |
Washer 1-1/2 OD X 15/32 ID X .250 Price: $4.99 |
| 42 |
539990247 |
LOCKWASHER.7/16 This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 47 |
532175288 |
Bushing Price: $3.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
Gasket Price: $9.99 |
| 70 |
532176069 |
Tube Exhaust LH Price: $51.99 |
| 71 |
532176070 |
Tube Exhaust RH Price: $53.99 |
| 79 |
532183906 |
Screw Socket Head 5/16-18 x 1 Price: $3.99 |
| 81 |
532188800 |
Oil Drain Tube Price: $2.99 |
| 82 |
532188799 |
Valve Drain Oil Price: $45.99 |
| 83 |
532171877 |
Bolt 5/16-18 unc x 1-3/4 W/Sems Price: $3.99 |
| 84 |
817060624 |
Screw 3/8-16 x 1-1/2 Price: $3.99 |
| 85 |
532179953 |
Bolt Hex 7/16-20 x 3.75 Gr. 5 Price: $3.99 |
