| Ref | Part Number | Description |
|---|
| 1 |
3296-60 |
NUT-LOCK, NI Price: $5.08 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532188713. Price: $142.99 |
| 2 |
104-3547 |
PULLEY-DRIVEN, DOUBLE Price: $218.26 |
| 2 |
532140551 |
SEAT PIVOT BRKT Price: $3.99 |
| 3 |
112-8446 |
SEAL-V RING This part replaces 104-3564. Price: $4.26 |
| 3 |
871110616 |
Bolt Fin Hex 3/8-16 unc x 1 Price: $2.99 |
| 4 |
119-4546 |
SPINDLE HOUSING ASM This part replaces 104-3552. Price: $244.67 |
| 4 |
819131610 |
WASHER PM Price: $3.99 |
| 5 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
104-3554 |
SHAFT-SPINDLE Price: $67.98 |
| 6 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 7 |
104-8322 |
WASHER-HARDENED Price: $23.22 |
| 7 |
539110300 |
SRPING.SEAT This part replaces 532124181. Price: $2.99 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 9 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131614. Price: $3.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $14.99 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $4.99 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT Price: $4.99 |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 21 |
532171852 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 22 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.69 |
| 24 |
819171912 |
WASHER Price: $3.99 |
