| Ref | Part Number | Description |
|---|
| 1 |
119-4763-01 |
COVER-BELT, RH This part replaces 72-9330. Price: $120.18 |
| 2 |
72-9230-01 |
BASE-CASE, GEAR This part replaces 72-9230. Price: $176.88 |
| 3 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 5 |
32128-20 |
NUT-HF Price: $0.99 |
| 6 |
72-9240-01 |
BRACKET-EXTENSION This part replaces 72-9240. Price: $23.69 |
| 7 |
322-4 |
SCREW-HH Price: $0.35 |
| 8 |
68-9890-01 |
COVER-GEARBOX, FRONT Price: $47.21 |
| 9 |
63-9750 |
MOUNT Price: $18.92 |
| 10 |
68-8560-03 |
BRACKET-GEARBOX This part replaces 68-8560. Price: $57.56 |
| 11 |
63-8410 |
WASHER Price: $1.76 |
| 12 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 13 |
93-6697 |
DECAL-LUBE Price: $11.38 |
| 14 |
108-1370 |
GEARBOX REPLACEMENT KIT This part replaces 106-4355. Price: $862.61 |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 16 |
323-4 |
SCREW-HH Price: $1.02 |
| 17 |
63-9900 |
GEARBOX PULLEY ASM Price: $135.09 |
| 18 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 19 |
27-6140 |
BUSHING-LOCK, TAPER Price: $84.79 |
| 20 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 21 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 22 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 23 |
119-4762-01 |
COVER-BELT, LH This part replaces 72-9340. Price: $114.44 |
| 24 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 25 |
3245-9 |
SCREW-SET, HSH Price: $0.81 |
| 26 |
3231-26 |
SCREW-CARR Price: $0.86 |
| 27 |
93-7043 |
RETAINER-LATCH Price: $13.09 |
| 28 |
321-8 |
SCREW-HH Price: $0.34 |
| 29 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 30 |
323-2 |
SCREW-HH Price: $0.68 |
| 31 |
107-2904 |
PTO GUARD ASM Price: $173.51 |
